Carrying Plate WT 2, Aluminum 12.7 mm, 1040 x 1040 mm - Bosch Rexroth 3842548685
Datasheet (PDF)
The product may differ from the illustration
Aluminum carrying plate (12.7 mm) for self-assembly of WT 2 workpiece pallets. Supplied fully drilled and ready to assemble, combinable with the WT 2 frame modules. Size 1040 x 1040 mm for pallets up to 100 kg total weight.

Carrying Plate WT 2, Aluminum 12.7 mm, 1040 x 1040 mm - Bosch Rexroth 3842548685

BOSCH REXROTH Original product
Net price (excl. VAT)
€1,363.32
Excl. 19% VAT , excl. Shipping Cost
Item BRR-3842548685
Manufacturer no. 3842548685
Personal expert advice
Brand new Specialist dealer since 2009 Original product Worldwide shipping
Product data
Manufacturer no.3842548685
Country of originGermany
Customs tariff number76169990
ConditionNew
Add to Wish List Add to Compare
Article
BRR-3842548685

The WT 2 carrying plate is used for self-assembly of WT 2 workpiece pallets with frame modules and fixing elements. Fully drilled and ready for assembly, it is intended for system integrators and maintenance teams who configure their own pallets for assembly and transfer systems.

  • Aluminum plate, 12.7 mm thick, for high rigidity
  • Large 1040 x 1040 mm format
  • Combinable with frame modules of the WT 2 workpiece pallet
  • Permissible pallet total weight up to 100 kg

Technical data

FeatureValue
Materialaluminum
Plate thickness12.7 mm
Workpiece pallet width (bWT)1040 mm
Workpiece pallet length (lWT)1040 mm
Flatness1.2 mm
Plate weight36.7 kg
Workpiece pallet total weight (max.)100 kg
Dimension a108.5 mm
Dimension c428.5 mm
Dimension d643.5 mm
Article number3842548685
More Information
ExecutionTEC
Manufacturer Nr.3842548685
ManufacturerBosch Rexroth
Country of ManufactureGermany
Weight0.009900
HS-Code76169990
GPSR manufacturer informationBosch Rexroth AG, Zum Eisengießer 1, DE-97816 Lohr am Main, www.boschrexroth.com
Article authenticityOriginal product
Condition of articleNew
