Pneumatic kit for unlocking the Lift Gate LG 2/H in the top end position. Supports the manual tilting mechanism that opens the conveyor section from 0° to 85°, securing reliable latch release at the upper stop. Designed for Bosch Rexroth assembly technology conveyor lines of the LG 2/H series.
Pneumatic Kit for Unlocking in the Top End Position, Lift Gate LG 2/H - Bosch Rexroth 3842549509
BOSCH REXROTH Original product
Net price (excl. VAT)
€206.58
Item BRR-3842549509
Manufacturer no. 3842549509
Personal expert advice
Brand new Specialist dealer since 2009 Original product Worldwide shipping
Product data
Manufacturer no.3842549509
Country of originGermany
Customs tariff number84313900
ConditionNew
Article
BRR-3842549509
Frequently Bought Together
- This Item: €206.58
- Adapter Set AS 2/R-V for LU 2 Lubrication Unit, TS 2plus - Bosch Rexroth 3842543487 €181.75
- Conveyor Section Profile ST 2/R-H, Anodized Aluminum, Slot 10 - Bosch Rexroth 3842536792 €5,812.21
Total price
The pneumatic kit 3842549509 is the dedicated accessory for unlocking the Bosch Rexroth Lift Gate LG 2/H in the top end position. The Lift Gate LG 2/H provides access or passage to interior areas of a conveyor line (BS) by manual tilting from 0° to 85° - a gas pressure spring reduces the effort required. This PN kit ensures pneumatic unlocking at the upper end position and is selected to match the applicable LG 2/H conveyor line types.
- Pneumatic unlocking at the top end position of the Lift Gate LG 2/H
- Compatible with Bosch Rexroth conveyor lines (BS) of the LG 2/H series
- Complements the gas pressure spring-assisted manual tilt mechanism
- Conveyor section opening angle: 0° to 85°
Technical data
| Specification | Value |
|---|---|
| Article number | 3842549509 |
| Type | PN kit for unlocking in the top end position |
| For use with | Lift Gate LG 2/H |
| Opening angle | 0° - 85° |
| Weight | 0.34 kg |
| ESD version | TEC |
|---|---|
| Manufacturer Nr. | 3842549509 |
| Manufacturer | Bosch Rexroth |
| Country of Manufacture | Germany |
| Weight | 0.009900 |
| HS-Code | 84313900 |
| GPSR manufacturer information | Bosch Rexroth AG, Zum Eisengießer 1, DE-97816 Lohr am Main, www.boschrexroth.com |
| Article authenticity | Original product |
| Condition of article | New |
| Position sensing | No |
