Cable Duct Corner HOR40x80 / VER80x40, ESD, PP Signal Gray - Bosch Rexroth 3842552258
Datasheet (PDF)
The product may differ from the illustration
A 90-degree corner piece in polypropylene for modular cable duct systems, bridging a horizontal 40x80 mm run to a vertical 80x40 mm run. The included potential equalizing cable makes two duct sections conductively connected, meeting ESD protection requirements. Push-in connecting elements are supplied.

Cable Duct Corner HOR40x80 / VER80x40, ESD, PP Signal Gray - Bosch Rexroth 3842552258

BOSCH REXROTH Original product
Net price (excl. VAT)
€23.57
Excl. 19% VAT , excl. Shipping Cost
Item BRR-3842552258
Manufacturer no. 3842552258
Personal expert advice
Brand new Specialist dealer since 2009 Original product Worldwide shipping
Product data
Manufacturer no.3842552258
Country of originItaly
Customs tariff number84313900
ConditionNew
Add to Wish List Add to Compare
Article
BRR-3842552258

The cable duct corner HOR40x80 / VER80x40 (part 3842552258) is a modular 90-degree connector for Bosch Rexroth cable duct systems. It redirects the duct path between a horizontal 40x80 mm profile and a vertical 80x40 mm profile. The supplied potential equalizing cable establishes a conductive link between two cable ducts, enabling defined ESD equipotential bonding in electrostatically protected areas (EPA).

  • 90-degree corner for horizontal and vertical duct routing in a single part
  • Push-in connecting elements included - no tools required for assembly
  • ESD-capable via the supplied potential equalizing cable
  • PP material in signal gray RAL 7004 - lightweight and durable
  • Compatible with corner sizes HOR40x40, HOR80x40, and HOR80x80 in the same series

Technical data

SpecificationValue
Part number3842552258
Horizontal dimensionHOR 40x80 mm
Vertical dimensionVER 80x40 mm
Angle90°
MaterialPP (polypropylene)
ColorSignal gray RAL 7004
ESDYes - via potential equalizing cable
Scope of deliveryCorner, connecting elements, potential equalizing cable
Packaging unit1 piece
Weight0.154 kg
More Information
ExecutionESD (antistatic)
Manufacturer Nr.3842552258
ManufacturerBosch Rexroth
Country of ManufactureItaly
Weight0.154000
HS-Code84313900
GPSR manufacturer informationBosch Rexroth AG, Zum Eisengießer 1, DE-97816 Lohr am Main, www.boschrexroth.com
Article authenticityOriginal product
Condition of articleNew
