Strut Profile 45x45, Anodized Aluminium, ESD-Suitable, Variable Length 50-6070 mm - Bosch Rexroth 3842990520-1000
Anodized aluminium strut profile 45x45 with 4 open slots and a 45 mm modular dimension for flexible use in assembly and workstation structures. ESD-suitable and supplied cut to variable lengths from 50 to 6070 mm.
Net
excl. VAT
€32.40
Item
BRR-3842990520-1000
Manufacturer no.
3842990520-1000
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
The Bosch Rexroth 45x45 strut profile is a standard-type aluminium structural profile with 4 open slots and a 45 mm modular dimension. It is designed for building assembly frames, machine bases, and ESD-safe workstation systems, and is supplied cut to your specified length.
- Variable length: 50 to 6070 mm - cut to order, no waste.
- ESD-suitable: Anodized surface meets the requirements of electrostatic-protected areas.
- 4 open slots: Profile slot 10, modular dimension 45 mm - direct integration with the Bosch Rexroth aluminium profile system.
- High rigidity: Area moment of inertia 13.8 cm⁴ (x and y), profile surface 7.5 cm² at a mass of 2 kg/m.
Technical data
| Property | Value |
|---|---|
| Cross-section | 45 x 45 mm |
| Profile type | Standard |
| Open slots | 4 |
| Profile slot | 10 |
| Modular dimension | 45 mm |
| Length min. (L min) | 50 mm |
| Length max. (L max) | 6070 mm |
| Condition on delivery | Variable length |
| Material | Aluminium, anodized |
| Color | Natural |
| ESD | Yes |
| Profile surface (A) | 7.5 cm² |
| Mass (m) | 2 kg/m |
| Area moment of inertia Ix | 13.8 cm⁴ |
| Area moment of inertia Iy | 13.8 cm⁴ |
| Moment of resistance Wx | 6.1 cm³ |
| Moment of resistance Wy | 6.1 cm³ |
| Torsional moment of inertia (It) | 2.65 cm⁴ |
| Moment of torsion resistance (Wt) | 0.96 cm³ |
| Packaging unit | 1 |
| Weight | 1.6 kg |
| Manufacturer | Bosch Rexroth |
| Manufacturer Nr. | 3842990520-1000 |
| HS-Code | 76042100 |
| GPSR manufacturer information | Bosch Rexroth AG, Zum Eisengießer 1, DE-97816 Lohr am Main, www.boschrexroth.com |
| Condition of article | New |
| Article authenticity | Original product |
| Country of Manufacture | Germany |
| ESD version | TEC |
