Strut Profile 90x90 2xM16-D22, 1000 mm - Bosch Rexroth 3842993083-1000

Name: Strut Profile 90x90 2xM16-D22, 1000 mm - Bosch Rexroth 3842993083-1000
Brand: Bosch Rexroth
SKU: BRR-3842993083-1000
Price: 131.57 EUR
Availability: InStock

Bosch Rexroth ✓ Original product Brand new Made in Germany

Anodized aluminum strut profile with a 90x90 mm cross-section, 8 open slots (slot size 10) and two M16 tapped holes (D22) for direct end-face bolting. Modular dimension 45 mm, length 1000 mm - designed for frames, machine structures and assembly systems within the Bosch Rexroth modular system.

Net

€131.57

excl. VAT

Item BRR-3842993083-1000

Manufacturer no. 3842993083-1000

Question about this item

Datasheet (PDF) 8 documents, all under Downloads

Specialist dealer since 2009
Invoice payment for regular customers
Worldwide shipping
Technical questions clarified with the manufacturer

Description

The strut profile 90x90 2xM16-D22 is an anodized aluminum profile with a square 90x90 mm cross-section and 8 open slots (slot size 10, modular dimension 45 mm). The integrated M16 tapped holes (D22) allow direct end-face bolting without separate end pieces, reducing assembly time in frame and machine structures. This profile is part of the Bosch Rexroth modular assembly system and is fully compatible with all 90x90 accessories.

High bending stiffness: area moment of inertia Ix/Iy 299.8 cm⁴ each, moment of resistance Wx/Wy 66.7 cm³ each
Good torsional stiffness: torsional moment of inertia It 118.6 cm⁴, moment of torsion resistance Wt 26 cm³
Flexible length selection: available from 120 mm to 6000 mm; this item: 1000 mm
System-compatible: works with connectors, brackets and cover caps of the 90x90 series
Natural anodized finish: corrosion-resistant and ready to use without additional coating

Technical data

Property	Value
Cross-section	90x90 mm
Length (this item)	1000 mm
Length min / max	120 mm / 6000 mm
Modular dimension	45 mm
Open slots	8
Slot size	10
Profile type	Standard
Material	Aluminum, anodized
Color	Natural
Profile surface A	38.4 cm²
Mass m	10.4 kg/m
Area moment of inertia Ix	299.8 cm⁴
Area moment of inertia Iy	299.8 cm⁴
Moment of resistance Wx	66.7 cm³
Moment of resistance Wy	66.7 cm³
Torsional moment of inertia It	118.6 cm⁴
Moment of torsion resistance Wt	26 cm³
Packaging unit	1
Weight	0.01 kg
Manufacturer	Bosch Rexroth
Manufacturer Nr.	3842993083-1000
HS-Code	76169990
GPSR manufacturer information	Bosch Rexroth AG, Zum Eisengießer 1, DE-97816 Lohr am Main, www.boschrexroth.com
Condition of article	New
Article authenticity	Original product
Country of Manufacture	Germany
ESD version	TEC
