Square aluminum strut profile 60x60 mm with 4 open slots (slot width 10 mm, modular dimension 60 mm) for modular machine frames, workstations, and guarding structures. Anodized aluminum in natural color provides lasting corrosion resistance at a linear mass of 3.9 kg/m. Available in lengths from 50 to 6070 mm with standard and customized profile finishing options.
Strut Profile 60x60 Q&E, Anodized Aluminum, 4 Slots - Bosch Rexroth 3842993668
BOSCH REXROTH
Original product
Net price (excl. VAT)
€55.68
Item
BRR-3842993668
Manufacturer no.
3842993668
Personal expert advice
Brand new
Specialist dealer since 2009
Original product
Worldwide shipping
Product data
Manufacturer no.3842993668
Country of originGermany
Customs tariff number76042100
ConditionNew
Article
BRR-3842993668
Frequently Bought Together
The Bosch Rexroth Strut Profile 60x60 Q&E is a symmetric square aluminum profile with 4 open slots and a 60 mm modular dimension - designed for flexible assembly of machine frames, workstations, protective enclosures, and conveyor structures. The anodized surface delivers permanent corrosion protection. The profile integrates directly into the Bosch Rexroth profile system, enabling fast, low-tool assembly with the full range of compatible connectors and fasteners.
- Symmetric 60x60 mm cross-section, profile surface 14.4 cm² - high load capacity with minimal material
- Area moment of inertia Ix = Iy = 52.2 cm⁴ and moment of resistance Wx = Wy = 17.4 cm³ - equal stiffness in both axes
- Torsional moment of inertia 15.9 cm⁴ and moment of torsion resistance 8.8 cm³ - suitable for torsionally loaded frame structures
- 10 mm slot width compatible with all Bosch Rexroth slot accessories: T-nuts, brackets, connectors
- Available from 50 to 6070 mm, single packaging unit, cut-to-length available
- Standard profile finishing: M12 / M16 / D9.8 / D17 / DB17 (observe minimum length)
- Customized profile finishing: DI / DIS / MT / MTS / MI / MIS / DG (DGmax = 45°, Lmin = 404/508 mm)
Technical data
| Property | Value |
|---|---|
| Cross-section | 60x60 mm |
| Profile type | Standard |
| Profile slot | 10 mm |
| Modular dimension | 60 mm |
| Open slots | 4 |
| Color | Natural (anodized) |
| Material | Aluminum, anodized |
| Length min. | 50 mm |
| Length max. | 6070 mm |
| Mass | 3.9 kg/m |
| Profile surface [A] | 14.4 cm² |
| Area moment of inertia Ix = Iy | 52.2 cm⁴ |
| Moment of resistance Wx = Wy | 17.4 cm³ |
| Torsional moment of inertia [It] | 15.9 cm⁴ |
| Moment of torsion resistance [Wt] | 8.8 cm³ |
| Standard profile finishing | M12 / M16 / D9.8 / D17 / DB17 |
| Customized profile finishing | DI / DIS / MT / MTS / MI / MIS / DG |
| Profile finishing notice | DGmax = 45°, Lmin = 404/508 mm |
| Packaging unit | 1 piece |
| Weight | 3.900000 |
|---|---|
| Manufacturer | Bosch Rexroth |
| Manufacturer Nr. | 3842993668 |
| HS-Code | 76042100 |
| GPSR manufacturer information | Bosch Rexroth AG, Zum Eisengießer 1, DE-97816 Lohr am Main, www.boschrexroth.com |
| Condition of article | New |
| Article authenticity | Original product |
| Country of Manufacture | Germany |
| ESD version | TEC |
