Protective frame made of anodized aluminum profile 30x30 WG40 with hot-galvanized steel woven wire grille 40x40x4 for 45x45 support systems. Available in widths from 250 to 1500 mm and heights up to 2300 mm. Supplied fully assembled for single-fitter installation via suspension brackets.
Protective Frame WG40 with Woven Wire Grille 40x40x4, Width 250-1500 mm - Bosch Rexroth 3842994742
BOSCH REXROTH Original product
Net price (excl. VAT)
€77.88
Item BRR-3842994742
Manufacturer no. 3842994742
Personal expert advice
Brand new Specialist dealer since 2009 Original product Worldwide shipping
Product data
Manufacturer no.3842994742
Country of originGermany
Customs tariff number76101000
ConditionNew
Article
BRR-3842994742
Frequently Bought Together
- This Item: €77.88
- Conveyor Section ST 2/R-100, 1000 mm, ESD-Suitable - Bosch Rexroth 3842994889-1000 €357.17
- Strut Profile 80x80L, 1000 mm, ESD-Compatible, Anodized Aluminum - Bosch Rexroth 3842993133-1000 €70.55
Total price
The 3842994742 protective frame provides effective machine guarding on Bosch Rexroth 45x45 support systems. The anodized aluminum WG40 profile (30x30 mm) carries a hot-galvanized steel woven wire grille with 40x40x4 mm mesh. An optional color coating improves visual contrast in the protected area and keeps access routes and emergency exits clearly visible. The frame arrives fully assembled and mounts to the supports via suspension brackets - a single fitter is sufficient. Standard widths and custom dimensions are available; horizontally or vertically divided frames add rigidity for large surface areas. Compatible kit sets allow the construction of system doors, sliding doors, and double doors.
- Anodized aluminum WG40 profile (30x30 mm) - corrosion-resistant and dimensionally stable
- Hot-galvanized steel woven wire grille 40x40x4 mm with optional color coating for improved contrast
- Width 250-1500 mm (modular dimension B referenced to 45x45 supports), height up to 2300 mm
- Fully assembled on delivery - single-fitter mounting via suspension brackets
- Extendable to system doors, sliding doors, and double doors using optional kit sets
Technical data
| Attribute | Value |
|---|---|
| Article number | 3842994742 |
| Frame profile type | WG40 (30x30 mm) |
| Woven wire grille | Steel, hot-galvanized, mesh 40x40x4 mm |
| Frame material | Aluminum, anodized |
| Width min. (B min) | 250 mm |
| Width max. (B max) | 1500 mm |
| Height min. (HR min) | 250 mm |
| Height max. (HR max) | 2300 mm |
| Modular dimension B | Referenced to 45x45 supports |
| Packaging unit | 1 |
| Weight | 0.0099 kg (base unit; actual weight varies by dimension) |
| ESD version | TEC |
|---|---|
| Manufacturer Nr. | 3842994742 |
| Manufacturer | Bosch Rexroth |
| Country of Manufacture | Germany |
| Weight | 0.009900 |
| HS-Code | 76101000 |
| GPSR manufacturer information | Bosch Rexroth AG, Zum Eisengießer 1, DE-97816 Lohr am Main, www.boschrexroth.com |
| Article authenticity | Original product |
| Condition of article | New |
| Position sensing | No |
