VarioFlow plus Aluminium Conveyor Section Profile, Variable Length 50-6000 mm - Bosch Rexroth 3842996026

Name: VarioFlow plus Aluminium Conveyor Section Profile, Variable Length 50-6000 mm - Bosch Rexroth 3842996026
Brand: Bosch Rexroth
SKU: BRR-3842996026
Price: 60.20 EUR
Availability: InStock

Bosch Rexroth ✓ Original product Brand new Made in Germany

Anodized aluminium section profile for the VarioFlow plus chain conveyor system, available in variable lengths from 50 mm to 6000 mm. Profile slot 10, sizes 65 to 320 mm. Supplied unassembled; requires slide rail, profile connector, and cross connector for installation.

Net

€60.20

excl. VAT

Item BRR-3842996026

Manufacturer no. 3842996026

Question about this item

Datasheet (PDF) 9 documents, all under Downloads

Specialist dealer since 2009
Invoice payment for regular customers
Worldwide shipping
Technical questions clarified with the manufacturer

Description

The VFplus AL section profile is the structural base element of track modules in the VarioFlow plus aluminium chain conveyor system. The anodized aluminium profile can be cut to any required length between 50 mm and 6000 mm, covering a wide range of track geometries in assembly technology applications.

Variable length 50 to 6000 mm - maximum flexibility in track layout planning
Anodized aluminium - corrosion-resistant and dimensionally stable over service life
Profile slot 10 for direct mounting of attachments without additional machining
Available in sizes 65, 90, 120, 160, 240, or 320 mm to match conveyed product width
Area moment of inertia Ix 11.22 cm⁴ / Iy 3.45 cm⁴ - defined stiffness values for track design
Delivery unit 1 piece, unassembled - straightforward stock management and on-demand cutting

Technical data

Parameter	Value
Material	Aluminum, anodized
Color	Natural
Delivery condition	Unassembled, variable length
Length min (L min)	50 mm
Length max (L max)	6000 mm
Size (b)	65 / 90 / 120 / 160 / 240 / 320 mm
Profile slot	10
Area moment of inertia Ix	11.22 cm⁴
Area moment of inertia Iy	3.45 cm⁴
Mass	1.1 kg/m
Delivery unit	1 piece
Recommended accessories	Cover profile
Required accessories	Slide rail, profile connector, cross connector, support profile (from size 160)
Weight	0.1 kg
Manufacturer	Bosch Rexroth
Manufacturer Nr.	3842996026
HS-Code	76042100
GPSR manufacturer information	Bosch Rexroth AG, Zum Eisengießer 1, DE-97816 Lohr am Main, www.boschrexroth.com
Condition of article	New
Article authenticity	Original product
Country of Manufacture	Germany
ESD version	TEC
