The LTS/F-3 lift transverse unit combines a belt section CSS/... with a lift unit to create right-angled branches in transfer systems. It supports 2 to 4 tracks with individually adjustable track spacing and two lift positions for flexible routing. O-rings deliver high friction for reliable cross-conveying, and toothed belts can be exchanged without specialist tools.
Lift Transverse Unit LTS/F-3, 2 to 4 Tracks, Track Width 240-600 mm - Bosch Rexroth 3842998683
BOSCH REXROTH Original product
Net price (excl. VAT)
€5,061.70
Item BRR-3842998683
Manufacturer no. 3842998683
Personal expert advice
Brand new Specialist dealer since 2009 Original product Worldwide shipping
Product data
Manufacturer no.3842998683
Country of originGermany
Customs tariff number84313900
ConditionNew
Article
BRR-3842998683
Frequently Bought Together
- This Item: €5,061.70
- Strut Profile 30x60° Anodized Aluminum, 20 Pieces x 6070 mm - Bosch Rexroth 3842557953 €1,984.57
- Stainless Steel Pipe 48.3 x 1.5 mm for VarioFlow plus STS Support - Bosch Rexroth 3842993308-1000 €66.19
Total price
The Bosch Rexroth LTS/F-3 lift transverse unit enables right-angled section branches in line conveyor systems. It consists of a belt section CSS/... and a lift unit, available in 2 to 4-track configurations with individually defined track spacings b1 to b3 - minimum dimensions must be observed.
- O-rings for high friction coefficients and improved static friction on the transverse conveyor
- Two lift positions for flexible line routing
- Toothed belts exchangeable without special tools
- Gear motors suitable for frequency converter operation
- Motor mounting on right (MA = R) or left (MA = L) selectable on each track of the belt section
- Motor connection via cable/plug (AT = S) or terminal box (AT = K)
- Tracks without lateral guide; reversible across the entire value range
- Supplied fully assembled; motors included separately
Technical data
| Parameter | Value |
|---|---|
| Version | LTS/F-3 |
| Number of tracks | 2 to 4 |
| Track width b1 (min.) | 240 mm |
| Track width b1 (max.) | 600 mm |
| Track width b2 (min.) | 216 mm |
| Track width b2 (max.) | 600 mm |
| Track width in transport direction b (min.) | 576 mm |
| Track width in transport direction b (max.) | 1320 mm |
| Length l (BG = 1) | 1264 to 6000 mm |
| Length l (BG = 2) | 1564 to 6000 mm |
| Length l (BG = 3) | 1864 to 6000 mm |
| Length l (BG = 4) | 2230 to 6000 mm |
| Length l (BG = 5) | 2530 to 6000 mm |
| Permissible load per track (LTS/F) | max. 0.15 kg/cm support surface, max. 40 kg |
| Permissible load per belt section | max. 120 kg |
| Motor mounting | Left or right per track (MS = 1 to 4) |
| Motor connection | Cable/plug (AT = S) or terminal box (AT = K) |
| Required accessory | Leg set SZS/B |
| Delivery state | Fully assembled; motors included separately |
| Execution | TEC |
|---|---|
| Manufacturer Nr. | 3842998683 |
| Manufacturer | Bosch Rexroth |
| Country of Manufacture | Germany |
| Weight | 0.009900 |
| HS-Code | 84313900 |
| GPSR manufacturer information | Bosch Rexroth AG, Zum Eisengießer 1, DE-97816 Lohr am Main, www.boschrexroth.com |
| Article authenticity | Original product |
| Condition of article | New |
| Position sensing | No |
