Damped Stop Gate VE 2/D100-H, Track Width 400-1200 mm, up to 100 kg - Bosch Rexroth 3842998747
Datasheet (PDF)
The product may differ from the illustration
The VE 2/D100-H stop gate arrests and releases workpiece pallets weighing 5 to 100 kg with a damped, rebound-free stop in the TS 2plus transfer system. The steel housing with aluminium cross strut mounts directly onto ST 2/... conveyor sections and covers track widths from 400 to 1200 mm. High-temperature versions and custom widths are available on request.

Damped Stop Gate VE 2/D100-H, Track Width 400-1200 mm, up to 100 kg - Bosch Rexroth 3842998747

BOSCH REXROTH Original product
Net price (excl. VAT)
€800.22
Excl. 19% VAT , excl. Shipping Cost
Item BRR-3842998747
Manufacturer no. 3842998747
Personal expert advice
Brand new Specialist dealer since 2009 Original product Worldwide shipping
Product data
Manufacturer no.3842998747
Country of originGermany
Customs tariff number84313900
ConditionNew
Add to Wish List Add to Compare
Article
BRR-3842998747
Frequently Bought Together
Total price

The VE 2/D100-H damped stop gate holds workpiece pallets precisely in position and releases them individually - without impact shock or rebound. Designed for the Bosch Rexroth TS 2plus transfer system, it handles medium to heavy pallets up to 100 kg total weight across a wide range of track widths.

  • Damped stop cam protects pallets and assemblies from shock loads
  • Covers track widths from 400 to 1200 mm with six preferred standard sizes
  • Suitable for workpiece pallets from 5 kg to 100 kg total weight
  • Steel housing and stop cam with aluminium cross strut for long service life and torsional rigidity
  • Mounts directly on ST 2/... conveyor section - all fastening hardware included
  • High-temperature version and non-standard widths available on request

Technical data

SpecificationValue
Track width min. [b min]400 mm
Track width max. [b max]1200 mm
Preferred track widths400, 480, 640, 800, 1040, 1200 mm
Min. workpiece pallet weight5 kg
Workpiece pallet total weight [mG]100 kg
Operating temperature0 ... +60 °C
HousingSteel
Stop camSteel
Cross strutAluminum
Scope of deliveryIncl. all fastening material for ST 2/... conveyor section
Delivery conditionNot assembled
Recommended accessoriesVE 2/RS-H Return Stop
More Information
ExecutionTEC
Manufacturer Nr.3842998747
ManufacturerBosch Rexroth
Country of ManufactureGermany
Weight0.100000
HS-Code84313900
GPSR manufacturer informationBosch Rexroth AG, Zum Eisengießer 1, DE-97816 Lohr am Main, www.boschrexroth.com
Article authenticityOriginal product
Condition of articleNew
