The EQ 2/T electrical transverse conveyor connects two parallel longitudinal sections and transfers workpiece pallets across the main conveying direction. The pre-assembled tandem module uses a toothed belt, is suitable for ESD-protected areas, and supports 2 or 3 pneumatic lift positions. Compatible with WT 2, WT 2/E and WT 2/F pallets.
EQ 2/T Electrical Transverse Conveyor, Size 2, Toothed Belt, ESD-Safe - Bosch Rexroth 3842999895
BOSCH REXROTH
Original product
Net price (excl. VAT)
€4,892.63
Item
BRR-3842999895
Manufacturer no.
3842999895
Personal expert advice
Brand new Specialist dealer since 2009 Original product Worldwide shipping
Product data
Manufacturer no.3842999895
Country of originGermany
Customs tariff number84283300
ConditionNew
Article
BRR-3842999895
Frequently Bought Together
- This Item: €4,892.63
- Lift Transverse Unit HQ 2/O, Size 1/2, ESD-compatible, 4-6 bar - Bosch Rexroth 3842998113 €1,193.02
- Protective Box SK2, 400x320 mm, Anodized Aluminum - Bosch Rexroth 3842345113 €229.26
Total price
The EQ 2/T (article 3842999895) is a pre-assembled transfer unit in the Bosch Rexroth TS 2plus modular conveyor system. It links two parallel longitudinal sections by moving workpiece pallets transversely, using a driven belt section in tandem design for spans from 320 mm. Reversible operation is supported; accumulation on the lift transverse units is not permitted.
- Size 2 from 480 x 480 mm upwards with two lifting cylinders per lift transverse unit - suited to larger transfer distances
- Pneumatic equipment for 2 (top, centre) or 3 (top, centre, bottom) lift positions - flexible line integration
- Transverse track width (bQ): 160, 240, 320, 400, 480, 640 or 800 mm
- Longitudinal track width (bL): 160, 240, 320, 400 or 480 mm
- Mounts on ST 2/... section (45 mm profile width) or ST 2/...-H section (50 mm profile width)
- Compatible with workpiece pallets WT 2, WT 2/E and WT 2/F
- Toothed belt conveyor medium, ESD-safe for use in EPA environments
- Energy efficiency to Rexroth 4EE standard
Technical data
| Parameter | Value |
|---|---|
| Article number | 3842999895 |
| Size | BG 1; BG 2 |
| Length (l) | 320 - 6,000 mm |
| Transverse track width (bQ) | 160; 240; 320; 400; 480; 640; 800 mm |
| Longitudinal track width (bL) | 160; 240; 320; 400; 480 mm |
| Nominal speed (vN) | 0; 6; 9; 12; 15; 18 m/min |
| Required compressed air connection | 4 - 6 bar |
| Pneumatic straight connection (dia.) | 6 mm |
| Max. section load in accumulation | 60 kg |
| Max. workpiece pallet weight | 30 kg |
| ESD-safe | Yes |
| Reversible operation | Yes |
| Motor connection (AT) | S (cable/plug) or K (terminal box) |
| Motor mounting (MA) | R (right), L (left), M (centre, from bQ ≥ 320 mm) |
| Pneumatic equipment (PN) | 2 (top + centre) or 3 (top + centre + bottom) |
| Scope of delivery | Pre-assembled unit incl. fastening material, 2x HQ 2/O, 1x BS 2/T, 2x connection kit, 2x housing element SK 2/B, assembly kit for electrical position sensing, pneumatic equipment |
| Weight (net) | 0.0099 kg (shipping unit) |
| ESD version | TEC |
|---|---|
| Manufacturer Nr. | 3842999895 |
| Manufacturer | Bosch Rexroth |
| Country of Manufacture | Germany |
| Weight | 0.009900 |
| HS-Code | 84283300 |
| GPSR manufacturer information | Bosch Rexroth AG, Zum Eisengießer 1, DE-97816 Lohr am Main, www.boschrexroth.com |
| Article authenticity | Original product |
| Condition of article | New |
| Position sensing | No |
