Belt Section BS 1/T with Toothed Belt, ESD-Suitable, Track Width 80-720 mm - Bosch Rexroth 3842999899

The BS 1/T belt section is a ready-to-operate conveyor unit for longitudinal transfer of workpiece pallets in segmented sections up to 5000 mm long. Drive is via a toothed belt with mesh top surface, qualified for use in ESD-protected areas (EPA). The motor is supplied separately and can be mounted on the right (MA = R), left (MA = L), or - at a track width of 160 mm - centrally (MA = M). Via the return unit, curves KE 1/O-90 or KE 1/O-180 can be driven using an attachment kit (included in the KE 1/O scope of delivery). Motor connection is available with cable and plug (AT = S) or terminal box (AT = K). Depending on the ordered length, the BS 1/T is delivered with two, three, or four cross connectors.

• Accumulation load up to 30 kg per section
• Track widths 80 to 720 mm, preferred values 80, 120, and 160 mm
• Length 320 to 5000 mm in segments
• ESD-suitable for use in EPA environments
• Drive of curves KE 1/O-90 or KE 1/O-180 via return unit
• Motor connection as cable/plug or terminal box
• Special variants available on request

Technical data
