Curve Unit KU 1/90 with Drive, 90-Degree Workpiece Carrier Transfer, ESD-Compatible - Bosch Rexroth 3842999986

The Bosch Rexroth KU 1/90 is a 90-degree curve module for the TS 1 transfer system, redirecting workpiece carriers while driving the curve and its attached belt sections from a single shared drive. Built-in accumulation means the module runs without elaborate control logic and drops directly into existing TS 1 layouts.

• Section loads up to 30 kg in accumulation mode
• ESD-compatible (EPA-rated) and certified to cleanroom class ISO 7
• Track widths 80, 120 or 160 mm - consistent with standard TS 1 modules
• Infeed and outfeed lengths freely selectable, lmax = 5000 mm
• Curve direction right (KR = R) or left (KR = L) - ordered as required
• Motor mounting internal (MA = I) or external (MA = A)
• Nominal speeds 6, 9, 12, 15 or 18 m/min (vN = 0: supplied without motor and gearbox)
• Dry-room rated to relative humidity below 1 %
• Rexroth 4EE energy-efficiency classification
