Miniature runner block MWA-020-SNS-C0-H-3 by Bosch Rexroth, material number R044209301. Size 20, material Corrosion-resistant, martensitic steel, accuracy class H - Highly accurate, preload class C0 - Without preload (clearance), seal LS - Low-friction seal (mini) and lubrication Pre-lubricated.
Miniature runner block MWA-020-SNS-C0-H-3 - Bosch Rexroth R044209301
BOSCH REXROTH
Original product
Net price (excl. VAT)
€88.70
Item
BRR-R044209301
Manufacturer no.
R044209301
Personal expert advice
Brand new
Specialist dealer since 2009
Original product
Worldwide shipping
Product data
Manufacturer no.R044209301
Country of originGermany
ConditionNew
Article
BRR-R044209301
Frequently Bought Together
-
This Item:
€88.70
-
Miniature runner block MWA-009-SNS-C1-H-0 - Bosch Rexroth R044281341
€44.34
-
Miniature runner block MWA-009-BNS-C0-N-0 - Bosch Rexroth R044389441
€57.03
Total price
Miniature runner block MWA-020-SNS-C0-H-3 by Bosch Rexroth, material number R044209301. Size 20, material Corrosion-resistant, martensitic steel, accuracy class H - Highly accurate, preload class C0 - Without preload (clearance), seal LS - Low-friction seal (mini) and lubrication Pre-lubricated. The dynamic load capacity is 7900 N. The static load capacity is 12230 N. Permissible values are up to 3 m/s travel speed and 250 m/s² acceleration. The weight is 0.27 kg.
Technical data
| Height runner block with guide rail | 25 mm |
|---|---|
| Pitch T guide rail | 60 mm |
| Ball chain | Without ball chain (standard) |
| Lubrication | Pre-lubricated |
| Maximum permissible linear speed vmax | 3 m/s |
| Nominal size | 20 |
| Static longitudinal moment load capacity ML0 footnote | Calculated values (derived from C, C<sub>0</sub>) |
| Preload class | C0 - Without preload (clearance) |
| Static load capacity C0 | 12230 N |
| Dynamic load capacity C50 | 9950 N |
| Material (profiled rail systems) | Corrosion-resistant, martensitic steel |
| Height of runner block | 17.5 mm |
| Format | SNS - slimline, normal, standard height |
| Static torsional moment load capacity Mt0 footnote | Calculated values (derived from C, C<sub>0</sub>) |
| Maximum acceleration rate amax | 250 m/s² |
| Dynamic load capacity C100 | 7900 N |
| Dynamic longitudinal moment load capacity ML50 | 65.1 Nm |
| Dynamic longitudinal moment load capacity ML100 | 51.7 Nm |
| Dynamic torsional moment load capacity Mt50 | 103 Nm |
| Length of runner block | 66 mm |
| Runner block or guide rail | Runner block |
| Width of runner block | 46 mm |
| Static torsional moment load capacity Mt0 | 126 Nm |
| Dynamic torsional moment load capacity Mt100 | 81.4 Nm |
| Dimension T1 min | 6.5 mm |
| Static longitudinal moment load capacity ML0 | 80 Nm |
| Linear guide type | Miniature ball rail system |
| Version | Ball rail system |
| Accuracy class | H - Highly accurate |
| Dimension B1 | 45.1 mm |
| Seal | LS - Low-friction seal (mini) |
| Permissible ambient temperature (min) | <prefix>-</prefix>10<suffix></suffix> °C |
| Permissible ambient temperature (max) | <prefix>+</prefix>80<suffix></suffix> °C |
| Weight | 0.27 kg |
| Permissible ambient temperature (min. ... max.) | -10 °C ... +80 °C |
| Manufacturer Nr. | R044209301 |
|---|---|
| Manufacturer | Bosch Rexroth |
| Country of Manufacture | Germany |
| Weight | 0.100000 |
| GPSR manufacturer information | Bosch Rexroth AG, Zum Eisengießer 1, DE-97816 Lohr am Main, www.boschrexroth.com |
| Article authenticity | Original product |
| Condition of article | New |
| Position sensing | No |
