Sem E C 16X10RX3-3 by Bosch Rexroth, material number R151204075. Size 16 x 10R x 3 - 3.
Sem E C 16X10RX3-3 - Bosch Rexroth R151204075
BOSCH REXROTH
Original product
Net price (excl. VAT)
€554.98
Item
BRR-R151204075
Manufacturer no.
R151204075
Personal expert advice
Brand new
Specialist dealer since 2009
Original product
Worldwide shipping
Product data
Manufacturer no.R151204075
Country of originGermany
ConditionNew
Article
BRR-R151204075
Frequently Bought Together
-
This Item:
€554.98
-
Lager LAF-B-Z 30 BG - Bosch Rexroth R159003000
€457.45
-
Ax Schr Kugellager LGN-C-3062 - Bosch Rexroth R341402306
€1,379.51
Total price
Sem E C 16X10RX3-3 by Bosch Rexroth, material number R151204075. Size 16 x 10R x 3 - 3. The static load capacity is 12300 N. Permissible values are up to 60 m/min travel speed. The weight is 0.33 kg.
Technical data
| Lead | 10 |
|---|---|
| Maximum permissible linear speed vmax (m/min) | 60 m/min |
| Direction of lead | Right |
| Nominal size | 16 x 10R x 3 - 3 |
| Screw drive seal | With seal |
| Static load capacity C0 | 12300 N |
| Series | Standard series |
| Bearing temperature min | <prefix>-</prefix>15<suffix></suffix> °C |
| Maximum operating temperature | <prefix>+</prefix>80<suffix></suffix> °C |
| Nut or screw | Screw drive nut |
| Bearing temperature max | <prefix>+</prefix>80<suffix></suffix> °C |
| Category | B |
| Minimum operating temperature | <prefix>-</prefix>10<suffix></suffix> °C |
| Hole pattern | BB2 |
| Dynamic load capacity C | 11500 N |
| Dimension d1 | 15 mm |
| Screw drive version (drive type) | Ball screw assembly |
| Nut type | SEM-E-C zero-clearance adjustable single nut |
| Weight | 0.33 kg |
| Storage temperature (min. … max.) | -15 °C ... +80 °C |
| Operating temperature (min. … max.) | -10 °C ... +80 °C |
| Manufacturer Nr. | R151204075 |
|---|---|
| Manufacturer | Bosch Rexroth |
| Country of Manufacture | Germany |
| Weight | 0.100000 |
| GPSR manufacturer information | Bosch Rexroth AG, Zum Eisengießer 1, DE-97816 Lohr am Main, www.boschrexroth.com |
| Article authenticity | Original product |
| Condition of article | New |
| Position sensing | No |
