Sem E S 63X20RX6,5-3 - Bosch Rexroth R151267014

Name: Sem E S 63X20RX6,5-3 - Bosch Rexroth R151267014
Brand: Bosch Rexroth
SKU: BRR-R151267014
Price: 984.03 EUR
Availability: InStock

Bosch Rexroth ✓ Original product Brand new Made in Germany

Sem E S 63X20RX6,5-3 by Bosch Rexroth, material number R151267014. Size 63 x 20R x 6,5 - 3.

Net

€984.03

excl. VAT

Item BRR-R151267014

Manufacturer no. R151267014

Question about this item

Datasheet (PDF) User manual 3 documents, all under Downloads

Specialist dealer since 2009
Invoice payment for regular customers
Worldwide shipping
Technical questions clarified with the manufacturer

Description

Sem E S 63X20RX6,5-3 by Bosch Rexroth, material number R151267014. Size 63 x 20R x 6,5 - 3. The static load capacity is 112100 N. Permissible values are up to 48 m/min travel speed. The weight is 4.16 kg.

Technical data

Lead	20
Maximum permissible linear speed vmax (m/min)	48 m/min
Direction of lead	Right
Nominal size	63 x 20R x 6,5 - 3
Screw drive seal	With seal
Static load capacity C0	112100 N
Series	Standard series
Bearing temperature min	<prefix>-</prefix>15<suffix></suffix> °C
Maximum operating temperature	<prefix>+</prefix>80<suffix></suffix> °C
Nut or screw	Screw drive nut
Bearing temperature max	<prefix>+</prefix>80<suffix></suffix> °C
Category	B
Minimum operating temperature	<prefix>-</prefix>10<suffix></suffix> °C
Hole pattern	BB7
Dynamic load capacity C	63800 N
Dimension d1	61 mm
Screw drive version (drive type)	Ball screw assembly
Nut type	SEM-E-S zero-clearance adjustable single nut
Weight	4.16 kg
Storage temperature (min. … max.)	-15 °C ... +80 °C
Operating temperature (min. … max.)	-10 °C ... +80 °C
Manufacturer	Bosch Rexroth
Manufacturer Nr.	R151267014
GPSR manufacturer information	Bosch Rexroth AG, Zum Eisengießer 1, DE-97816 Lohr am Main, www.boschrexroth.com
Condition of article	New
Article authenticity	Original product
Country of Manufacture	Germany
