Measuring pin EMC100 by Bosch Rexroth, material number R15616A007. Size 100 and material stainless steel.
Measuring pin EMC100 - Bosch Rexroth R15616A007
BOSCH REXROTH
Original product
Net price (excl. VAT)
€2,999.92
Item
BRR-R15616A007
Manufacturer no.
R15616A007
Personal expert advice
Brand new
Specialist dealer since 2009
Original product
Worldwide shipping
Product data
Manufacturer no.R15616A007
Country of originGermany
ConditionNew
Article
BRR-R15616A007
Frequently Bought Together
-
This Item:
€2,999.92
-
Flange mounting EMC80 - Bosch Rexroth R15615A002
€90.11
-
Ausgleichkupplung Flexo EMC50/63 - Bosch Rexroth R349938100
€91.38
Total price
Measuring pin EMC100 by Bosch Rexroth, material number R15616A007. Size 100 and material stainless steel. The weight is 0.15 kg.
Technical data
| Suitable for drag chains | Yes |
|---|---|
| Power supply voltage tolerance | <prefix>±</prefix>2<suffix></suffix> V |
| Power supply voltage | 24 V |
| Measurement range | 45 kN |
| Current consumption | <prefix></prefix>25<suffix></suffix> mA |
| Output signal (measuring range) tolerance | <prefix>±</prefix>0.2<suffix></suffix> V |
| Connector outlet | angled |
| Nominal size | 100 |
| Rated current | 4 A |
| Rated voltage | 250 V |
| Repeatability (of the measuring range) | <prefix>±</prefix>0.25<suffix></suffix> % |
| Max. zero setting function (tare) | 24 V |
| Min. zero setting function (tare) | 7.2 V |
| Max. ambient temperature, in motion | <prefix></prefix>+80<suffix></suffix> °C |
| Product information | with connection cable |
| Maximum operating temperature | <prefix>+</prefix>60<suffix></suffix> °C |
| Cable diameter D | 5.9 mm |
| Cable diameter D tolerance | <prefix>±</prefix>0.2<suffix></suffix> mm |
| Dynamic bending radius | <gt/> 5xD |
| Static bending radius | <gt/> 10xD |
| Electrical accessories for electromechanical cylinders | Force sensors |
| Minimum operating temperature | <prefix>-</prefix>20<suffix></suffix> °C |
| Connection type 2 | Flying leads |
| Protection class | IP65 |
| Output signal with tolerance | 0 V ±0,03 |
| Connection type 1 | Female connector, M12, 4-pin |
| Breaking load (of the measuring range) | 300 % |
| Output signal tolerance | <prefix>±</prefix>0.03<suffix></suffix> V |
| Hardness | 38 HRC HRC |
| Operating load (of the measuring range) | 150 % |
| Output signal | 0 V |
| Bandwidth tolerance | <prefix>±</prefix>0.2<suffix></suffix> kHz |
| Bandwidth with tolerance | 2,5 kHz ±0,2 |
| Connection | Connector M12x1 |
| Bandwidth | 2.5 kHz |
| Hysteresis (of the measuring range) | <prefix>±</prefix>0.2<suffix></suffix> % |
| Output signal (measuring range) min | <prefix>-</prefix>10<suffix></suffix> V |
| Non-linearity (of the measuring range) | <prefix>±</prefix>0.5<suffix></suffix> % |
| Output signal (measuring range) with tolerance | -10 ... +10 V ±0,2 |
| Output signal (measuring range) max | <prefix>+</prefix>10<suffix></suffix> V |
| Compensated temperature min | <prefix>+</prefix>10<suffix></suffix> °C |
| Min. ambient temperature, in motion | <prefix></prefix>-40<suffix></suffix> °C |
| Measurement inaccuracy | <prefix>±</prefix>0.23<suffix></suffix> kN |
| Cable material | PUR |
| Cable color | Black |
| Manufacturer Nr. | R15616A007 |
|---|---|
| Manufacturer | Bosch Rexroth |
| Country of Manufacture | Germany |
| Weight | 0.100000 |
| GPSR manufacturer information | Bosch Rexroth AG, Zum Eisengießer 1, DE-97816 Lohr am Main, www.boschrexroth.com |
| Article authenticity | Original product |
| Condition of article | New |
| Position sensing | No |
