Measuring pin EMC-105-HD - Bosch Rexroth R156347080

Name: Measuring pin EMC-105-HD - Bosch Rexroth R156347080
Brand: Bosch Rexroth
SKU: BRR-R156347080
Price: 3080.04 EUR
Availability: InStock

Bosch Rexroth ✓ Original product Brand new Made in Germany

Measuring pin EMC-105-HD by Bosch Rexroth, material number R156347080. Size 130 and material stainless steel.

Net

€3,080.04

excl. VAT

Item BRR-R156347080

Manufacturer no. R156347080

Question about this item

Datasheet (PDF) User manual 6 documents, all under Downloads

Specialist dealer since 2009
Invoice payment for regular customers
Worldwide shipping
Technical questions clarified with the manufacturer

Description

Measuring pin EMC-105-HD by Bosch Rexroth, material number R156347080. Size 130 and material stainless steel. The weight is 1.3 kg.

Technical data

Suitable for drag chains	Yes
Power supply voltage tolerance	<prefix>±</prefix>2<suffix></suffix> V
Power supply voltage	24 V
Measurement range	80 kN
Current consumption	<prefix>max.</prefix>50<suffix></suffix> mA
Output signal (measuring range) tolerance	<prefix>±</prefix>0.2<suffix></suffix> V
Connector outlet	angled
Nominal size	130
Rated current	4 A
Rated voltage	250 V
Repeatability (of the measuring range)	<prefix>±</prefix>0.25<suffix></suffix> %
Max. zero setting function (tare)	24 V
Min. zero setting function (tare)	7.2 V
Max. ambient temperature, in motion	<prefix></prefix>+80<suffix></suffix> °C
Maximum operating temperature	<prefix>+</prefix>60<suffix></suffix> °C
Cable diameter D	5.9 mm
Cable diameter D tolerance	<prefix>±</prefix>0.2<suffix></suffix> mm
Dynamic bending radius	<gt/> 5xD
Static bending radius	<gt/> 10xD
Electrical accessories for electromechanical cylinders	Force sensors
Minimum operating temperature	<prefix>-</prefix>20<suffix></suffix> °C
Connection type 2	Flying leads
Protection class	IP65
Output signal with tolerance	0 V ±0,03
Connection type 1	Female connector, M12, 4-pin
Breaking load (of the measuring range)	300 %
Output signal tolerance	<prefix>±</prefix>0.03<suffix></suffix> V
Hardness	38 HRC HRC
Operating load (of the measuring range)	150 %
Output signal	0 V
Bandwidth tolerance	<prefix>±</prefix>0.2<suffix></suffix> kHz
Bandwidth with tolerance	2,5 kHz ±0,2
Connection	Connector M12x1
Bandwidth	2.5 kHz
Hysteresis (of the measuring range)	<prefix>±</prefix>0.2<suffix></suffix> %
Output signal (measuring range) min	<prefix>-</prefix>10<suffix></suffix> V
Non-linearity (of the measuring range)	<prefix>±</prefix>0.5<suffix></suffix> %
Output signal (measuring range) with tolerance	-10 ... +10 V ±0,2
Output signal (measuring range) max	<prefix>+</prefix>10<suffix></suffix> V
Compensated temperature min	<prefix>+</prefix>10<suffix></suffix> °C
Min. ambient temperature, in motion	<prefix></prefix>-40<suffix></suffix> °C
Cable material	PUR
Cable color	Black
Temperature drift zero point (of the measuring range per Kel	<prefix>±</prefix>0.05<suffix></suffix> %
Shield	yes
Weight	1.3 kg
Manufacturer	Bosch Rexroth
Manufacturer Nr.	R156347080
GPSR manufacturer information	Bosch Rexroth AG, Zum Eisengießer 1, DE-97816 Lohr am Main, www.boschrexroth.com
Condition of article	New
Article authenticity	Original product
Country of Manufacture	Germany
