Bosch Rexroth R186132210. Rollenwagen CS RWA-125-FNS-C2-P-2
Rollenwagen CS RWA-125-FNS-C2-P-2 by Bosch Rexroth, material number R186132210. Size 125, material Carbon steel, accuracy class P - Precise, preload class C2 - Medium preload, seal SS - Standard seal and lubrication Preserved.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
Rollenwagen CS RWA-125-FNS-C2-P-2 by Bosch Rexroth, material number R186132210. Size 125, material Carbon steel, accuracy class P - Precise, preload class C2 - Medium preload, seal SS - Standard seal and lubrication Preserved. The dynamic load capacity is 757200 N. The static load capacity is 1324000 N. Permissible values are up to 2 m/s travel speed and 150 m/s² acceleration. The weight is 62.1 kg.
Technical data
| Friction coefficient μ | 0.0004 ... 0.001 |
|---|---|
| Height runner block with guide rail | 160 mm |
| Pitch T guide rail | 120 mm |
| Nominal size | 125 |
| Preload class | C2 - Medium preload |
| Static load capacity C0 | 1324000 N |
| Height of runner block | 135.5 mm |
| Format | FNS - flange, normal, standard height |
| Length of runner block | 371 mm |
| Runner block or guide rail | Runner block |
| Width of runner block | 320 mm |
| Static torsional moment load capacity Mt0 | 95330 Nm |
| Dynamic torsional moment load capacity Mt100 | 54520 Nm |
| Static longitudinal moment load capacity ML0 | 51860 Nm |
| Linear guide type | Roller rail system |
| Version | Roller rail systems |
| Accuracy class | P - Precise |
| Dimension B1 | 255 mm |
| Friction force FR | 600 N |
| Friction coefficient μ min. | 0.0004 |
| Model | Heavy-duty roller runner block |
| Lubrication | Preserved |
| Maximum permissible linear speed vmax | 2 m/s |
| Friction coefficient μ max. | 0.001 |
| Dynamic load capacity C50 | 931000 N |
| Material (profiled rail systems) | Carbon steel |
| Preload force | 60600 N |
| Maximum acceleration rate amax | 150 m/s² |
| Dynamic load capacity C100 | 757200 N |
| Dynamic longitudinal moment load capacity ML50 | 36500 Nm |
| Dynamic longitudinal moment load capacity ML100 | 29660 Nm |
| Dynamic torsional moment load capacity Mt50 | 67100 Nm |
| Dimension T1 min | 40 mm |
| Seal | SS - Standard seal |
| Permissible ambient temperature (min) | <prefix>-</prefix>10<suffix></suffix> °C |
| Permissible ambient temperature (max) | <prefix>+</prefix>80<suffix></suffix> °C |
| Weight | 62.1 kg |
| Permissible ambient temperature (min. ... max.) | -10 °C ... +80 °C |
| Manufacturer | Bosch Rexroth |
| Manufacturer Nr. | R186132210 |
| GPSR manufacturer information | Bosch Rexroth AG, Zum Eisengießer 1, DE-97816 Lohr am Main, www.boschrexroth.com |
| Condition of article | New |
| Article authenticity | Original product |
| Country of Manufacture | Germany |
| Norm | DIN ISO 14728-1 |
| Preload | C2 |
