Roller runner block RWA-125-FNS-C2-H-2 - Bosch Rexroth R186132360

Images are examples, some edited with AI. The technical data are authoritative. AI notice

Roller runner block RWA-125-FNS-C2-H-2 - Bosch Rexroth R186132360

Bosch Rexroth ✓ Original product Brand new Made in Germany

Roller runner block RWA-125-FNS-C2-H-2 by Bosch Rexroth, material number R186132360. Size 125, material Hard chrome plated, accuracy class H - Highly accurate, preload class C2 - Medium preload, seal SS - Standard seal and lubrication Preserved.

Net
€7,051.91
excl. VAT
Item BRR-R186132360
Manufacturer no. R186132360
Save Compare
Question about this item
Datasheet (PDF) User manual 5 documents, all under Downloads
  • Specialist dealer since 2009
  • Invoice payment for regular customers
  • Worldwide shipping
  • Technical questions clarified with the manufacturer

Description

Roller runner block RWA-125-FNS-C2-H-2 by Bosch Rexroth, material number R186132360. Size 125, material Hard chrome plated, accuracy class H - Highly accurate, preload class C2 - Medium preload, seal SS - Standard seal and lubrication Preserved. The dynamic load capacity is 757200 N. The static load capacity is 1324000 N. Permissible values are up to 2 m/s travel speed and 150 m/s² acceleration. The weight is 62.1 kg.

Technical data

Friction coefficient μ0.0004 ... 0.001
Height runner block with guide rail160 mm
Pitch T guide rail120 mm
Nominal size125
Preload classC2 - Medium preload
Static load capacity C01324000 N
Height of runner block135.5 mm
FormatFNS - flange, normal, standard height
Length of runner block371 mm
Runner block or guide railRunner block
Width of runner block320 mm
Static torsional moment load capacity Mt095330 Nm
Dynamic torsional moment load capacity Mt10054520 Nm
Static longitudinal moment load capacity ML051860 Nm
Linear guide typeRoller rail system
VersionRoller rail systems
Accuracy classH - Highly accurate
Dimension B1255 mm
Friction force FR600 N
Friction coefficient μ min.0.0004
ModelHeavy-duty roller runner block
LubricationPreserved
Maximum permissible linear speed vmax2 m/s
Friction coefficient μ max.0.001
Dynamic load capacity C50931000 N
Material (profiled rail systems)Hard chrome plated
Preload force60600 N
Maximum acceleration rate amax150 m/s²
Dynamic load capacity C100757200 N
Dynamic longitudinal moment load capacity ML5036500 Nm
Dynamic longitudinal moment load capacity ML10029660 Nm
Dynamic torsional moment load capacity Mt5067100 Nm
Dimension T1 min40 mm
SealSS - Standard seal
Permissible ambient temperature (min)<prefix>-</prefix>10<suffix></suffix> °C
Permissible ambient temperature (max)<prefix>+</prefix>80<suffix></suffix> °C
Weight62.1 kg
Permissible ambient temperature (min. ... max.)-10 °C ... +80 °C
ManufacturerBosch Rexroth
Manufacturer Nr.R186132360
GPSR manufacturer informationBosch Rexroth AG, Zum Eisengießer 1, DE-97816 Lohr am Main, www.boschrexroth.com
Condition of articleNew
Article authenticityOriginal product
Country of ManufactureGermany
