Bosch Rexroth R186323110. Rollenwagen CS RWA-100-FLS-C3-S-2
Rollenwagen CS RWA-100-FLS-C3-S-2 by Bosch Rexroth, material number R186323110. Size 100, material Carbon steel, accuracy class SP - Super precise, preload class C3 - High preload, seal SS - Standard seal and lubrication Preserved.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
Rollenwagen CS RWA-100-FLS-C3-S-2 by Bosch Rexroth, material number R186323110. Size 100, material Carbon steel, accuracy class SP - Super precise, preload class C3 - High preload, seal SS - Standard seal and lubrication Preserved. The dynamic load capacity is 632000 N. The static load capacity is 1218000 N. Permissible values are up to 2 m/s travel speed and 150 m/s² acceleration. The weight is 42 kg.
Technical data
| Friction coefficient μ | 0.0004 ... 0.001 |
|---|---|
| Height runner block with guide rail | 120 mm |
| Pitch T guide rail | 105 mm |
| Nominal size | 100 |
| Preload class | C3 - High preload |
| Static load capacity C0 | 1218000 N |
| Height of runner block | 105 mm |
| Format | FLS - flange, long, standard height |
| Length of runner block | 380.5 mm |
| Runner block or guide rail | Runner block |
| Width of runner block | 250 mm |
| Static torsional moment load capacity Mt0 | 71200 Nm |
| Dynamic torsional moment load capacity Mt100 | 35300 Nm |
| Static longitudinal moment load capacity ML0 | 52400 Nm |
| Linear guide type | Roller rail system |
| Version | Roller rail systems |
| Accuracy class | SP - Super precise |
| Dimension B1 | 288 mm |
| Friction force FR | 400 N |
| Friction coefficient μ min. | 0.0004 |
| Model | Heavy-duty roller runner block |
| Lubrication | Preserved |
| Maximum permissible linear speed vmax | 2 m/s |
| Friction coefficient μ max. | 0.001 |
| Dynamic load capacity C50 | 777000 N |
| Material (profiled rail systems) | Carbon steel |
| Preload force | 82200 N |
| Maximum acceleration rate amax | 150 m/s² |
| Dynamic load capacity C100 | 632000 N |
| Dynamic longitudinal moment load capacity ML50 | 33500 Nm |
| Dynamic longitudinal moment load capacity ML100 | 27200 Nm |
| Dynamic torsional moment load capacity Mt50 | 43400 Nm |
| Dimension T1 min | 35 mm |
| Seal | SS - Standard seal |
| Permissible ambient temperature (min) | <prefix>-</prefix>10<suffix></suffix> °C |
| Permissible ambient temperature (max) | <prefix>+</prefix>80<suffix></suffix> °C |
| Weight | 42 kg |
| Permissible ambient temperature (min. ... max.) | -10 °C ... +80 °C |
| Manufacturer | Bosch Rexroth |
| Manufacturer Nr. | R186323110 |
| GPSR manufacturer information | Bosch Rexroth AG, Zum Eisengießer 1, DE-97816 Lohr am Main, www.boschrexroth.com |
| Condition of article | New |
| Article authenticity | Original product |
| Country of Manufacture | Germany |
| Norm | DIN ISO 14728-1 |
| Preload | C3 - high preload |
