Bosch Rexroth R186332310. Rollenwagen CS RWA-125-FLS-C2-H-2

Name: Bosch Rexroth R186332310. Rollenwagen CS RWA-125-FLS-C2-H-2
Brand: Bosch Rexroth
SKU: BRR-R186332310
Price: 5190.20 EUR
Availability: InStock

Bosch Rexroth ✓ Original product Brand new Made in Germany

Net

€5,190.20

excl. VAT

Item BRR-R186332310

Manufacturer no. R186332310

Question about this item

Datasheet (PDF) User manual 5 documents, all under Downloads

Specialist dealer since 2009
Invoice payment for regular customers
Worldwide shipping
Technical questions clarified with the manufacturer

Description

Rollenwagen CS RWA-125-FLS-C2-H-2 by Bosch Rexroth, material number R186332310. Size 125, material Carbon steel, accuracy class H - Highly accurate, preload class C2 - Medium preload, seal SS - Standard seal and lubrication Preserved. The dynamic load capacity is 1020000 N. The static load capacity is 1941900 N. Permissible values are up to 2 m/s travel speed and 150 m/s² acceleration. The weight is 99.5 kg.

Technical data

Friction coefficient μ	0.0004 ... 0.001
Height runner block with guide rail	160 mm
Pitch T guide rail	120 mm
Nominal size	125
Preload class	C2 - Medium preload
Static load capacity C0	1941900 N
Height of runner block	135.5 mm
Format	FLS - flange, long, standard height
Length of runner block	476 mm
Runner block or guide rail	Runner block
Width of runner block	320 mm
Static torsional moment load capacity Mt0	139820 Nm
Dynamic torsional moment load capacity Mt100	75350 Nm
Static longitudinal moment load capacity ML0	109150 Nm
Linear guide type	Roller rail system
Version	Roller rail systems
Accuracy class	H - Highly accurate
Dimension B1	360 mm
Friction force FR	600 N
Friction coefficient μ min.	0.0004
Model	Heavy-duty roller runner block
Lubrication	Preserved
Maximum permissible linear speed vmax	2 m/s
Friction coefficient μ max.	0.001
Dynamic load capacity C50	1250000 N
Material (profiled rail systems)	Carbon steel
Preload force	81600 N
Maximum acceleration rate amax	150 m/s²
Dynamic load capacity C100	1020000 N
Dynamic longitudinal moment load capacity ML50	72300 Nm
Dynamic longitudinal moment load capacity ML100	58820 Nm
Dynamic torsional moment load capacity Mt50	92700 Nm
Dimension T1 min	40 mm
Seal	SS - Standard seal
Permissible ambient temperature (min)	<prefix>-</prefix>10<suffix></suffix> °C
Permissible ambient temperature (max)	<prefix>+</prefix>80<suffix></suffix> °C
Weight	99.5 kg
Permissible ambient temperature (min. ... max.)	-10 °C ... +80 °C
Manufacturer	Bosch Rexroth
Manufacturer Nr.	R186332310
GPSR manufacturer information	Bosch Rexroth AG, Zum Eisengießer 1, DE-97816 Lohr am Main, www.boschrexroth.com
Condition of article	New
Article authenticity	Original product
Country of Manufacture	Germany
Norm	DIN ISO 14728-1
Preload	C2
