The socket marked S receives the plug and holds it in place. Like the plug it is built in stainless steel with an EPDM seal. It is connected through a male thread. Model CZL-1SM, stainless steel, Seal material EPDM.
Quick connect coupling Compact Zero Spill Cupla CZL-1SM, stainless steel - Nitto Kohki 349865628
NITTO KOHKI
Original product
Net price (excl. VAT)
€99.80
Item
NKH-349865628
Manufacturer no.
349865628
Personal expert advice
Brand new
Specialist dealer since 2009
Original product
Worldwide shipping
Product data
Manufacturer no.349865628
ConditionNew
Article
NKH-349865628
Frequently Bought Together
Breaking a liquid line should leave nothing dripping and nothing running out. The Nitto Kohki Compact Zero Spill Cupla is designed for spill-free disconnection and has a stainless steel body.
- Design for spill-free disconnection, the fluid stays in the line when the coupling is broken
- Stainless steel body on every model in the range
- EPDM as the sealing material across the whole range
- Compact build, which keeps the space needed at the coupling point small
- Two sizes in the CZL model range, each available as a socket marked S and as a plug marked P, both with a male thread
Technical data from the manufacturer catalogue
| Series | COMPACT ZEROSPILL CUPLA |
|---|---|
| Model | CZL-1SM |
| Coupling part | Socket |
| End connection | Male thread |
| Port size | Rc 1/8 |
| Body material | Stainless Steel (SUS304), Nickel plated on Socket body |
| Seal material | Ethylene-propylene rubber (EPDM) |
| Max working pressure | 1.0 MPa {10 kgf/cm2, 10 bar, 145 PSI} |
| Working temperature | Ethylene-propylene rubber (EPDM): -10 °C to +100 °C |
| Valve structure | Two-way shut-off (Spill Reduction) |
| Applicable fluids | Air, Water |
| Vacuum service | Please contact us if vacuum is required for your application. |
| Size range | Thread 1/8 inch, 1/4 inch |
| Pressure unit table | Working pressure 1.0 MPa, 10 kgf/cm2, 10 bar, 145 PSI |
| Maximum tightening torque in Nm {kgf.cm} | 1/8 inch: 9 {92}, 1/4 inch: 14 {143} |
| Flow direction | Fluid flow can be bi-directional when socket and plug are connected. |
| Socket outer diameter | CZL-1SM: 16 mm, CZL-2SM: 18.5 mm |
| WAF | WAF stands for width across flats. |
| Mass | 0.050 kg |
| Part number | 349865628 |
| Catalogue page | C01en-b, 29 |
Dimensions
| Model | L | T | øH (WAF) | øoD |
|---|---|---|---|---|
| CZL-1SM | (53) | R 1/8 | Hex.13 | 16 |
Dimensions in millimetres. Values in brackets apply in the connected condition.
Legend: L = overall length; T = thread or barb size
Models in this series COMPACT ZEROSPILL CUPLA
| Model | Application | Stainless steel (g) | L | T | øH (WAF) | øoD |
|---|---|---|---|---|---|---|
| CZL-1SM | Rc 1/8 | 38 | (53) | R 1/8 | Hex.13 | 16 |
| CZL-2SM | Rc 1/4 | 49 | (55.5) | R 1/4 | Hex.16 | 18.5 |
Every model of the series as printed in the manufacturer catalogue. The row of the article offered here is highlighted.
Operating principle
- Compact size saves space. Outer diameters of 16 mm (CZL-1SM) and 18.5 mm (CZL-2SM).
- High flow rate for efficient cooling.
- Easy operation, push-to-connect function.
- Valve structure reduces air inclusion on connection and liquid spillage when disconnecting.
- Small, high flow type for coolant piping.
Series comparison
| Series | Max working pressure | Size range | Valve structure | Applicable fluids |
|---|---|---|---|---|
| COMPACT ZEROSPILL CUPLA | 10 bar | Thread 1/8 inch, 1/4 inch | Two-way shut-off (Spill Reduction) | Air, Water |
| PURGE LINE CUPLA | 10 bar | Inlet R 1/2, outlet socket (PV-30SM) | One-way shut-off | Air |
| HI CUPLA BL | 15 bar | 1/4 inch, 3/8 inch, 1/2 inch (thread and hose barb); SN type for urethane hose: for 6.5 x 10 mm, 8 x 12 mm and 8.5 x 12.5 mm hose | One-way shut-off | Air, Water |
| NUT CUPLA / NUT CUPLA 200 / ROTARY NUT CUPLA / HI CUPLA for Connection to Braided Hoses | 15 bar | Urethane hose ø5 mm x ø8 mm to ø11 mm x ø16 mm; braided hose ø9 mm x ø15 mm | One-way shut-off | Air, Water |
| LOCK CUPLA 200 | 15 bar | Thread and hose barb 1/4 inch, 3/8 inch, 1/2 inch; SNRG type for ø6.5 mm x ø10 mm and ø8.5 mm x ø12.5 mm hose | One-way shut-off | Air |
| HI CUPLA Two Way Type | 15 bar | Thread 1/4 inch, 3/8 inch, 1/2 inch. Hose barb for dia. 6.5 mm x dia. 10 mm and dia. 8.5 mm x dia. 12.5 mm hose. | One-way shut-off | Air |
| PURGE HI CUPLA | 15 bar | PVR Type: thread 1/2 inch, 3/4 inch, 1 inch; hose barb 1/2 inch, 3/4 inch, 1 inch hose. PV Type: thread 1/4 inch, 3/8 inch, 1/2 inch, 3/4 inch | One-way shut-off | Air |
| ROTARY LINE CUPLA | 15 bar | RT Type (for two branch lines): inlet HI CUPLA Plug 20PF, outlet 2 sockets for HI CUPLA Socket Model 20. RE Type (for three branch lines): inlet R 1/2, outlet 3 sockets for HI CUPLA Socket Model 20. | One-way shut-off | Air |
Choose COMPACT ZEROSPILL CUPLA when air inclusion on connection and liquid spillage on disconnection have to be limited: it is two-way shut-off with spill reduction, while the sibling series in this group - HI CUPLA BL, NUT CUPLA, LOCK CUPLA 200, PURGE LINE CUPLA and ROTARY LINE CUPLA - are one-way shut-off. Its socket outer diameter of 16 mm (CZL-1SM) or 18.5 mm (CZL-2SM) in sizes 1/8 inch and 1/4 inch suits coolant piping in tight space. If the line runs up to 1.5 MPa {15 kgf/cm2}, one of the one-way shut-off peers is the better choice, because this series is rated 1.0 MPa {10 kgf/cm2}.
Body and seal materials
| Body material |
|---|
| Stainless Steel (SUS304), Nickel plated on Socket body |
| Seal material | Mark | Working temperature | Remarks |
|---|---|---|---|
| Ethylene-propylene rubber | EPDM | -10 °C to +100 °C | Standard material |
Applications
- Liquid circuits in which no fluid may escape on disconnection
- Installations that require stainless steel on the wetted parts
- Coupling points with little installation space
- Equipment disconnected often for servicing
Safety and application notes
- Before use, please be sure to read "Safety Guide" described at the end of this book and "Instruction Sheet" that comes with the products.
All technical data on this page is taken from the Nitto Kohki general catalogue Quick Connect Couplings C01en-b, page 29. The complete catalogue is available for download on this page.
| Manufacturer Nr. | 349865628 |
|---|---|
| Manufacturer | Nitto Kohki |
| Weight | 0.050000 |
| GPSR manufacturer information | Nitto Kohki Europe GmbH, Gottlieb-Daimler-Str. 10, DE-71144 Steinenbronn, www.nitto-kohki.eu |
| Article authenticity | Original product |
| Condition of article | New |
| Dichtungen | EPDM |
| Anschlussgewinde | Rc 1/8 |
| Medientemperatur [°C] | EPDM -10 ... +100 °C |
| Material | Stainless steel |
| Betriebsdruck max [bar] | 10.000000 |
| Overall length [mm] | 53.000000 |
