Statfree DLR2 ESD Rubber Matting Roll, 2-Layer, Blue, 2 mm, 1.22 x 10 m - Desco 228082
Two-layer Statfree DLR2 ESD rubber matting in blue, 2 mm thick, as a roll 1.22 x 10 m. Dissipative top and conductive bottom give Rg 1 x 10^6 to < 1 x 10^8 ohms per IEC 61340-5-1. Solder-iron resistant, withstands chemicals and is easy to clean.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
On an ESD worksurface, components, tools and the mat should sit at the same potential so that charges drain in a controlled way rather than in a sudden discharge. The Statfree DLR2 rubber mat in blue (roll 1.22 x 10 m) reaches a resistance to ground of 1 x 106 to < 1 x 108 ohms and withstands soldering irons, heat and most chemicals.
Key benefits
- Two-layer build: the dissipative top layer at 1 x 106 to < 1 x 109 ohms drains charges in a controlled way, and the conductive bottom layer spreads them across the whole mat to the ground point.
- Resistance to ground Rg 1 x 106 to < 1 x 108 ohms, well below the 1 x 109 ohm limit of IEC 61340-5-1.
- Withstands soldering iron contact and common maintenance chemicals per EN 423, abrasion below 200 mm3.
- Matt, low-reflecting, non-slip surface that is easy to clean.
- Well suited to workstations with a continuous monitor.
Applications
Worksurfaces for assembly, soldering, repair and testing of electronic assemblies, lab and goods-in benches, and shelf and trolley surfaces in the EPA.
Standards
Top layer, bottom layer and resistance to ground meet the IEC 61340-5-1 requirements for worksurfaces. The rubber is vulcanised and may contain sulphur, and colour and texture can vary slightly between lots.
Technical data
| Item number | 228082 |
|---|---|
| Manufacturer | Desco |
| Product line | Statfree DLR2 |
| Top layer colour | Blue |
| Size | 1.22 x 10 m |
| Construction | 2 layers: coloured dissipative top, black conductive bottom, vulcanised rubber |
| Rp-p top layer | 1 x 106 to < 1 x 109 ohms |
| Rp-p bottom layer | < 1 x 106 ohms |
| Resistance to ground Rg | 1 x 106 to < 1 x 108 ohms |
| Thickness | 2 mm (± 0.15 mm), 1 mm per layer |
| Hardness | 75 ± 5 Shore A (ISO 7619) |
| Abrasion | < 200 mm3 (ISO 4649, method A) |
| Chemical resistance | common maintenance chemicals (EN 423) |
| Weight per area | 2.7 kg/m2 |
| Corners | square (full roll) |
| Weight | 34.8 kg |
| Country of origin | Italy |
| Manufacturer Nr. | 228082 |
| HS-Code | 40169100 |
| GPSR manufacturer information | A1-ESD equipment GmbH. Keldersstr. 15, DE-42697 Solingen, www.esd.equipment |
| Condition of article | New |
| Article authenticity | Original product |
| Country of Manufacture | Italy |
| Sales unit | Rolle 1,22 x 10 m |
| Height | 2 mm |
| Width | 1220 mm |
| Depth | 10000 mm |
| Abmessung | 1,22 x 10 m |
| Colour | Blue |
| ESD version | ESD (antistatic) |
| ESD-Eigenschaft | dissipative |
| Certification | IEC 61340-5-1 |
Scope of delivery
One roll 1.22 x 10 m, 2 mm thick. Ground snap and ground cord are sold separately. Connect each mat to its own ground point and do not daisy-chain mats, as the total resistance may exceed the limit.
