ESD In-Plant Handler with Lid and Partitions, Cell Size 305 x 102 x 70 mm - Desco 37358
Impregnated corrugated handler with partitions and lid for circuit boards and assemblies, cell size 305 x 102 x 70 mm. Discharge shielding below 10 nJ with the lid in place, surface 10^6 to 10^9 ohms, assembled without tape or staples.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
Moving several boards or assemblies between process steps needs a separate cell for each part and protection from discharges. The Desco Protektive Pak in-plant handler is a box of impregnated corrugated board with partitions and a lid. Each cell measures 305 x 102 x 70 mm. With the lid in place discharge shielding is below 10 nJ per ANSI/ESD STM11.31.
Key benefits
- Shields contents from charges and discharges with the lid in place, discharge shielding < 10 nJ.
- Each assembly in its own cell, no part-to-part contact, plus physical protection.
- Adjustable double thick partitions, reversible for longer use.
- Dissipative surface of 1 x 106 to < 1 x 109 ohms, buried shielding layer with low sloughing.
- Assembled without tape, glue or staples. Made from 100% recycled material and 100% recyclable.
Applications
In-plant transport and buffer storage of circuit boards and assemblies between placement, test and assembly, kitting and line-side supply.
Standards
Meets the required limits of ANSI/ESD S20.20 and packaging standard ANSI/ESD S541. Surface resistance tested per ANSI/ESD STM11.11, discharge shielding per ANSI/ESD STM11.31.
Technical data
| Part number | 37358 |
|---|---|
| Manufacturer | Desco (Protektive Pak) |
| Cell size (L x W x D) | 305 x 102 x 70 mm |
| Features | double thick partitions, adjustable and reversible, lid included |
| Material | impregnated corrugated board with buried shielding layer |
| Surface resistance | 1 x 106 to < 1 x 109 ohms (ANSI/ESD STM11.11) |
| Discharge shielding | < 10 nJ (ANSI/ESD STM11.31) |
| Walls | double sides, double (under 6 in deep) or triple ends |
| Assembly | no tape, glue or staples |
| Country of origin | USA |
| Sales unit | 1 piece |
| Weight | 0.1 kg |
| Manufacturer Nr. | 37358 |
| GPSR manufacturer information | A1-ESD equipment GmbH. Keldersstr. 15, DE-42697 Solingen, www.esd.equipment |
| Condition of article | New |
| Article authenticity | Original product |
| Abmessung | 305 x 102 x 70 mm |
| ESD version | ESD (antistatic) |
| ESD-Eigenschaft | shielding |
Scope of delivery
Supplied as a box with partitions and lid. No tooling costs.
