ESD Inplant Handler, Adjustable, with Lid, 102 x 95 to 203 x 248 mm - Desco

Desco (Protektive Pak) Inplant Handlers are compartment boxes for sorted, ESD-safe storage and transport of sensitive components and circuit boards. Every version is made of impregnated dissipative corrugated board measuring 1 x 10⁶ to < 1 x 10⁹ ohms and comes with a lid. With the lid closed, the contents are shielded from external charges and discharges.

Choose the size to suit part dimensions and quantity: versions range from 102 x 95 mm to 203 x 248 mm at 25 mm height and differ in the number of cells.

Key benefits

• Dissipative surface of 1 x 10⁶ to < 1 x 10⁹ ohms per ANSI/ESD STM11.11
• Shielding effect with the lid closed
• Up to 30 combinations with the same container, lid and partitions
• Impregnated material, the ESD property does not rub off
• Reusable over many cycles

Applications

Storage and in-plant transport of circuit boards, modules and loose components in production, goods-in, repair and picking inside an EPA.

Standards

Surface resistance tested per ANSI/ESD STM11.11. Suitable for ESD control programs per ANSI/ESD S20.20 and IEC 61340-5-1.
