ESD Storage Container Plastek, Conductive, Steel Frame, 581 x 327 x 464 mm - Desco 39104

Bulky assemblies, housings or larger quantities of parts need a sturdy container that drains charges under load and replaces cardboard where it is not allowed. The Plastek storage container measuring 581 x 327 x 464 mm is made of extruded, permanently conductive polypropylene at 1 x 10² to < 1 x 10⁵ ohms. A steel wire frame stiffens the container and the conductive plastic handle keeps the path to ground while carrying.

Key benefits

• Permanently conductive at 1 x 10² to < 1 x 10⁵ ohms, independent of humidity
• Rolled-over double-thickness sides and steel wire frame for high load capacity
• Conductive handle for safe carrying with a path to ground
• Chemical and moisture resistant, temperature range -27 °C to +110 °C
• Marked with the ESD protective symbol per ANSI/ESD S541, ships assembled

Applications

Storage and transport of larger ESD sensitive parts and assemblies in production, stores and shipping, especially in clean rooms and cardboard-free areas.

Standards

Meets ANSI/ESD S20.20 and packaging standard ANSI/ESD S541.
