ESD floor tile GTI EL5 Cleantech, conductive, 65 x 65 cm, Blue - Gerflor 3552-0354
Item 3552-0354
€0.00
Images are examples, some edited with AI. The technical data are authoritative. AI notice
ESD floor tile GTI EL5 Cleantech, conductive, 65 x 65 cm, Grey - Gerflor 3552-0352
Conductive ESD floor tile GTI EL5 Cleantech in Grey, 65 x 65 cm, overall thickness 6.0 mm. 5 x 10^4
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
Conductive ESD floor tile GTI EL5 Cleantech in Grey, 65 x 65 cm, overall thickness 6.0 mm. 5 x 10^4 <= Rt <= 10^6 Ohm (EN 1081).
Benefits
- Permanently conductive through the full thickness, with no loss of effect over time
- Installation: laid without adhesive, straight edges for heat welding
- Use class 34 - 43 to EN ISO 10874, the highest commercial and industrial rating
- Reaction to fire Bfl-s1 to EN 13501-1, slip resistance R9 to DIN 51130
- TVOC below 10 µg/m³ after 28 days (ISO 16000-6), FloorScore certified
Installation
The covering is connected to the equipotential bonding, earthed through a copper strip grid in the substrate. Resistance has to be measured and documented on the finished floor to IEC 61340-4-1 after installation. Manufacturer values apply before installation.
Standards and conformity
Complies with IEC 61340-5-1 and ANSI/ESD S20.20 (ESD control), EN ISO 10581 or EN ISO 10582 (product standard), EN 13501-1 (reaction to fire) and EN 14041 (CE marking). Data sheet, installation and cleaning instructions are available for download in the category.
Price on request. We calculate quantity, waste allowance, welding rod and accessories for your project.
Technical data
| Material | heterogeneous vinyl tile to EN ISO 10582, binder content type I |
|---|---|
| Colour | 0352 Grey (NCS 3005-B20G, light reflectance value LRV 35.5) |
| Format | 65 x 65 cm (0.4225 m² per unit) |
| Overall thickness | 6.0 mm, wear layer 2.0 mm |
| Weight per area | 9240 g/m² to EN ISO 23997 |
| Electrical resistance | 5 x 104 ≤ Rt ≤ 106 Ω (EN 1081) |
| Body voltage generation | below 2 kV to EN 1815 |
| Gerflor article number | 3552-0352 |
| Weight | 3.9 kg |
| Manufacturer | Gerflor |
| Manufacturer Nr. | 3552-0352 |
| HS-Code | 39181090 |
| GPSR manufacturer information | Gerflor Mipolam GmbH Mülheimer Straße 27 DE-53840 Troisdorf www.gerflor.de |
| Condition of article | New |
| Article authenticity | Original product |
| Country of Manufacture | France |
| Sales unit | 1 Stück |
| Height | 6 |
| Width | 650 |
| Depth | 650 |
| Farbe | grau |
| Ausführung | GTI EL5 Cleantech |
| ESD version | ESD (antistatic) |
| ESD equipment | ESD Bodenbelag |
| ESD-Eigenschaft | conductive |
| Norm | ANSI/ESD S20.20, DIN EN 1081, DIN EN 12529, DIN EN 16000-6, ISO 10582, ISO 10874, ISO 23997 |
| Certification | DIN 51130, EN 1815, EN 13501-1, IEC 61340-4-1, IEC 61340-4-5, IEC 61340-5-1 |
