ESD sheet flooring Mipolam Robust EL7, dissipative, roll 2 x 20 m, Pewter - Gerflor 4135-0013
Dissipative ESD sheet flooring Mipolam Robust EL7 in Pewter, roll 2 x 20 m, overall thickness 2.0 mm. 10^6
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
Dissipative ESD sheet flooring Mipolam Robust EL7 in Pewter, roll 2 x 20 m, overall thickness 2.0 mm. 10^6 <= Rt <= 10^8 Ohm (EN 1081).
Benefits
- Permanently dissipative through the full thickness, with no loss of effect over time
- Installation: fully bonded, also available as a 608 x 608 mm tile
- Use class 34 - 43 to EN ISO 10874, the highest commercial and industrial rating
- Reaction to fire Bfl-s1 to EN 13501-1, slip resistance R9 to DIN 51130
- TVOC below 10 µg/m³ after 28 days (ISO 16000-6), FloorScore certified
Installation
The covering is connected to the equipotential bonding, earthed through a copper strip grid in the substrate. Resistance has to be measured and documented on the finished floor to IEC 61340-4-1 after installation. Manufacturer values apply before installation.
Standards and conformity
Complies with IEC 61340-5-1 and ANSI/ESD S20.20 (ESD control), EN ISO 10581 or EN ISO 10582 (product standard), EN 13501-1 (reaction to fire) and EN 14041 (CE marking). Data sheet, installation and cleaning instructions are available for download in the category.
Price on request. We calculate quantity, waste allowance, welding rod and accessories for your project.
Technical data
| Material | homogeneous PVC to EN ISO 10581, binder content type II |
|---|---|
| Colour | 0013 Pewter (NCS 6502-B, light reflectance value LRV 18.2) |
| Format | roll 2 x 20 m (40 m² per unit) |
| Overall thickness | 2.0 mm, wear layer 2.0 mm |
| Weight per area | 3300 g/m² to EN ISO 23997 |
| Electrical resistance | 106 ≤ Rt ≤ 108 Ω (EN 1081) |
| Body voltage generation | below 2 kV to EN 1815 |
| Gerflor article number | 4135-0013 |
| Weight | 132 kg |
| Manufacturer | Gerflor |
| Manufacturer Nr. | 4135-0013 |
| HS-Code | 39181090 |
| GPSR manufacturer information | Gerflor Mipolam GmbH Mülheimer Straße 27 DE-53840 Troisdorf www.gerflor.de |
| Condition of article | New |
| Article authenticity | Original product |
| Sales unit | Rolle 2 x 20 m (40 m²) |
| Height | 2 |
| Width | 2000 |
| Depth | 20000 |
| Farbe | dunkelgrau |
| Ausführung | Mipolam Robust EL7 |
| ESD version | ESD (antistatic) |
| ESD equipment | ESD Bodenbelag |
| ESD-Eigenschaft | dissipative |
| Norm | ANSI/ESD S20.20, DIN EN 1081, DIN EN 12529, DIN EN 16000-6, ISO 10582, ISO 10874, ISO 23997 |
| Certification | DIN 51130, EN 1815, EN 13501-1, IEC 61340-4-1, IEC 61340-4-5, IEC 61340-5-1 |
Downloads
User Manual
Declaration of Conformity
Brochure
