Glamox FXX589342. Interior General Lighting FX45-P2023 0/100 AL 4000 DALI 840 C2.5 MP/PC

Name: Glamox FXX589342. Interior General Lighting FX45-P2023 0/100 AL 4000 DALI 840 C2.5 MP/PC
Brand: Glamox
SKU: GL-FXX589342
Price: 303.8 EUR
Availability: InStock

Lead time

6 weeks

€303.80

Excl. 19% VAT , excl. Shipping Cost

Article

GL-FXX589342

Manufacturer Nr.

FXX589342

FX45-P2023 0/100 AL 4000 DALI 840 C2.5 MP/PC

Skip to the end of the images gallery

Skip to the beginning of the images gallery

The product may differ from the illustration

Frequently Bought Together

This Item: Glamox FXX589342. Interior General Lighting FX45-P2023 0/100 AL 4000 DALI 840 C2.5 MP/PC
€303.80
Excl. 19% VAT , excl. Shipping Cost
Glamox C80547519. Systemleuchten C80-SR/RR1122 G2 LU 2000 MO HF 830 DIF
€115.50
Excl. 19% VAT , excl. Shipping Cost
Glamox C80547497. Systemleuchten C80-SR/RR1682 G2 LU 5400 HO HF 830 DIF
€143.50
Excl. 19% VAT , excl. Shipping Cost

Total price

Details

General
1. Product shape
  Linear
Texts
1. Remarks
  Suspension wire and bracket for surfaced mounting has to be ordered separately
Certificates
1. Certification
  HACCP
LMS System
1. Number of DALI addresses
  1
2. LMS Protocol
  DALI
Technical Data
1. Minimum ambient temperature (ºC)
  0
2. Maximum ambient temperature (°C)
  25
3. IK classification
  07
4. IP classification
  20
Light Technical Data
1. Light source
  LED
2. Lumen out (lm)
  4,000
3. Lumen per Watt (lm/W)
  103
4. Lamp colour temp (K)
  4000
5. CRI Colour rendering index
  80
6. Light distribution up %
  0
7. Light distribution down %
  100
8. MacAdam step
  3
9. Energy class light source
  C
10. Minimum dim level (%)
  1
11. Light source included
  Yes
Driver / Ballast
1. Type of LED Driver
  DALI: Dimming

Lifetime
1. L80 Median useful life LED Ta25 (hr)
  100 000
2. Median useful life driver Ta25 (hr)
  100,000
3. Luminous flux decline (LLMF) 50.000h Ta25
  0.90
Electrical Data
1. Voltage from (V)
  220
2. Maximum voltage (V)
  240
3. Minimum frequency (Hz)
  50
4. Maximum frequency (Hz)
  60
5. Total consumption (W)
  39
6. IEC Protection Class
  I
7. Number of luminaires on a 10A MCB type B (80% load)
  13
8. Number of luminaires on a 10A MCB type C (80% load)
  21
9. Number of luminaires on a 16A MCB type B (80% load)
  21
10. Number of luminaires on a 16A MCB type C (80% load)
  35
Optic
1. Optic
  MP/PC - Micro prismatic diffuser with polycarbonate cover
2. Material of diffuser
  Polycarbonate
3. Diffuser material design
  Prismatic
Housing
1. Main body material
  Aluminium
2. Body colour
  Grey
3. Main body colour name
  Grey
4. Main body colour surface
  Anodized
Dimensions
1. Length (mm)
  2,023
2. Width (mm)
  44
3. Height (mm)
  65
4. Net weight (kg)
  4.28
Mounting
1. Product mounting
  Pendant,Surface,Ceiling Surface,Trunking
Logistic Data
1. Item gross weight (kg)
  4.65

Information

More Information
Manufacturer Nr.	FXX589342
Manufacturer	Glamox
EAN	5901155893422
Lead time	6 weeks
Weight	4.650000
Colour	4000K
Lenght	2023
GPSR manufacturer information	Glamox GmbH Daimlerring 25 DE-31135 Hildesheim www.glamox.com
Article authenticity	Original product
Condition of article	New
