Digital torque tester with handpiece for measuring loosening and retightening torque on fastened screws from 0.15 to 10.00 Nm. Colour display, USB charger and aluminium case.
Screw Torque Tester 0.15-10 Nm - HIOS HDP-100 2025
HIOS
Original product
Net price (excl. VAT)
€2,574.00
Item
HDP-100 2025
Manufacturer no.
HDP-100 2025
Personal expert advice
Brand new
Specialist dealer since 2009
Original product
Worldwide shipping
Product data
Manufacturer no.HDP-100 2025
ConditionNew
Article
HDP-100 2025
Frequently Bought Together
-
This Item:
€2,574.00
-
Cordless Industrial Straight Grinder IGS/A 10.8V bare tool, boxed - Proxxon 29852
€96.64
-
Kilews Power supply SKP-12HL for B100 series
€121.89
Total price
The HIOS HDP-100 checks the torque actually applied to a fastened screw in a range of 0.15 to 10.00 Nm. The handpiece with 1/4 inch bit holder captures loosening or retightening torque, the separate main unit shows value and curve.
Features
- Measures loosening and retightening torque on fastened screws
- Handpiece with sensor and 1/4 inch bit holder connected to a separate main unit
- 3.5 inch colour display with torque curve
- PASS/FAIL judgement with adjustable limits
- Wireless data transfer via Bluetooth to PC or PLC
- Accuracy ±0.5 % of full scale
- USB charger, supplied in an aluminium case
- Made in Japan
Technical data
| Measuring range | 0.15-10.00 Nm (15-1000 Ncm) |
| Handpiece bit holder | 1/4" hex |
| Accuracy | ±0.5 % of full scale |
| Measuring modes | PEAK, F.PEAK, TR1, TR2 |
| Direction | clockwise and counter-clockwise |
| Minimum display | 10 digit |
| Display | 3.5 inch colour display with curve view |
| Interfaces | Bluetooth, Micro-USB type B, RS-232C optional |
| Battery | NiMH 3.6 V, 1000 mAh |
| Operating time | up to 2.5 hours |
| Charging time | 5 hours |
| AC adapter | AC 100-240 V 50/60 Hz, DC 5 V 2 A |
| Operating environment | 15-35 °C, 25-65 % RH, non-condensing |
| Main unit (W x D x H) | 134 x 100 x 36 mm |
| Main unit weight | 495 g |
| Sensor cable | 2 m |
Application
For checking assembled screw joints in the medium torque range, for sample inspections in quality assurance and for incoming goods inspection.
Compatibility
USB AC adapter: HPNN-ACSET-PSE. For testing the screwdrivers themselves use the HP-100 2025, for low torques up to 0.5 Nm the HDP-5 2025.
| Manufacturer Nr. | HDP-100 2025 |
|---|---|
| Manufacturer | Hios |
| GPSR manufacturer information | A1-ESD equipment GmbH. Keldersstr. 15, DE-42697 Solingen, www.esd.equipment |
| Article authenticity | Original product |
| Condition of article | New |
