ESD personnel tester Test Station EVO RFID-PLUS Ethernet 125 kHz and 13.56 MHz - Iteco 9264929P

Where two card generations are in circulation at the same time or where a large EPA workforce has to be documented without gaps, a single RFID band is not enough. The RFID-PLUS version reads both 125 kHz and 13.56 MHz cards, holds up to 1000 users and files 25,000 accesses in the internal data logger.

Benefits in daily EPA operation

• Two RFID bands in one instrument, 125 kHz and 13.56 MHz are recognised without switching over
• 1000 stored users instead of the 200 offered by the single frequency RFID models
• Data logger with 25,000 accesses, which extends the recording period until the next evaluation considerably
• The only model of the series approved for the additional RFID sensor Iteco 9266103 that registers the exit
• LAN RJ45 connection, relay output max. 60 V, 1 A, 50 VA for door opener or turnstile
• Measuring range 50 kΩ to 2 GΩ for wrist strap and per shoe, accuracy ±10 %, test voltage 50 V or 100 V

Technical data

Applications

Suitable for plants with a mixed card population after a system migration, for shift operations with large headcount and for entrances where entry and exit have to be recorded separately.

Compatibility and scope of delivery

Supplied are the instrument, the plug-in power supply and the evaluation software. Footplate Iteco 9264965 and stand Iteco 9264953 are ordered separately, exit registration adds the auxiliary sensor Iteco 9266103 and access control the turnstile Iteco 9266100.

Standards and origin

Wrist strap and footwear testing follows IEC 61340-5-1. An ISO9000 traceable calibration certificate is supplied with the instrument, and periodic recalibration can be ordered as Iteco 9264927. The Test Station EVO is manufactured in Italy.
