roller conveyor QUADRO, transfer line over 2/3 of table width, 1020x400 mm, table frame 1650 mm - Karl 55.643.72

Roll workpiece carriers and transport containers from workstation to workstation instead of carrying them: this QUADRO roller conveyor forms a 1020 mm transfer line on a 1650 mm wide QUADRO table frame. The space beside the line takes a side table-top element as a work surface.

Benefits

• Transfer line over 2/3 of the table width: 1020 mm conveyor on a 1650 mm table.
• Track width 400 mm, matched to end stops and workpiece carriers of the same size.
• For mounting on the QUADRO table frame (base or add-on element for roller and flanged-roller rails, width 1650 mm).
• KARL transfer system components from a single source, designed to work together.

Matching accessories and variants

• ESD version to IEC 61340-5-1: KARL 55.643.70
• Transfer line over the full table width (1650 mm): KARL 55.645.72
• End stop for roller conveyor, track width 400 mm: KARL 59.175.70
• Side table-top element in high-pressure laminate, table width 1650 mm: KARL 55.794.88 (outfeed right) or 55.795.88 (left)
• workpiece carrier 400 x 400 mm with mat: KARL 59.715.98

Applications

• Linked assembly workstations with workpiece carrier transfer
• Transport and order picking of containers between workstations
• Assembly in industry and equipment manufacturing
