Workpiece carrier 300x400 mm, rubber covering, 27 mm - Karl 59.710.98

Pass workpieces along a transfer line from one workstation to the next without handling them: the KARL workpiece carrier in 300 x 400 mm format takes up to 35 kg, and its rubber covering keeps the part in place during transport and assembly.

Benefits

• Top side with anti-slip rubber covering in platinum grey: workpieces stay put when the carrier is pushed on.
• Underside with high-pressure laminate covering for running on roller strips and ball elements.
• Hard-wearing edge banding protects the edges, total thickness 27 mm.
• Max. load capacity 35 kg as specified by the manufacturer.
• On request KARL builds custom workpiece carriers and sizes, also with inserted threaded bushings for workpiece fixtures.

Matching accessories and variants

• Same size without covering: KARL 59.709.98
• Same size with rubber covering, ESD version to IEC 61340-5-1: KARL 59.711.98
• SINTRO ball-roller table top for 300 x 400 mm workpiece carriers, through-table 1230 mm: KARL 56.810.88
• SINTRO corner element, universal corner plate for workpiece carriers from 300 to 600 mm: KARL 56.895.88

Applications

• Transfer lines in assembly and production
• Linked assembly and test workstations with roller strips and ball-roller table tops
• Diverting to repair and test stations with transport trolleys for workpiece carriers
