Platform Scale 150 kg Readability 0,01 kg - KERN EFC 100K-3L
The KERN EFC 100K-3L is a mobile platform scale for loads up to 150 kg with 0,01 kg readability. Its built-in Li-Ion battery runs for up to 50 h, so the scale is ready to use at changing locations. The LED display with 52 mm digit height stays easy to read even in poor light.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
The KERN EFC 100K-3L weighs goods, containers and parts up to 150 kg with 0,01 kg readability, and its battery power lets you set it up wherever the weighing happens, in production, the warehouse or dispatch. The generous stainless steel weighing plate takes bulky loads, and the value shows on the bright LED display with 52 mm digit height.
Benefits
- Mains-independent: built-in Li-Ion battery for up to 50 h of operation (30 h with backlight), no fixed socket needed.
- Easy to read: LED segment display with 52 mm digit height and high contrast, even in poor light.
- Check weighing: visual and audible signal supports portioning, dosing and sorting.
- Parts counting: counting from a minimum piece weight of 5 g under laboratory conditions.
- Data output: RS-232 as standard for direct connection of a printer.
- Rugged weighing surface: stainless steel plate 600×500 mm on a coated steel base.
Compliance and origin
EAN 4045761252639, customs tariff number 84238220, country of origin China.
Technical data
| Weighing range (max) | 150 kg |
|---|---|
| Readability (d) | 0,01 kg |
| Repeatability | 0,01 kg |
| Linearity | ± 0,03 kg |
| Weighing system | strain gauge |
| Minimum piece weight (parts counting, lab conditions) | 5 g |
| Weighing surface (W×D) | 600×500 mm |
| Display | LED segment, 52 mm digit height |
| Units | kg, lb, PCS |
| Interface | RS-232 as standard |
| Power supply | Li-Ion battery and mains adapter |
| Battery life | up to 50 h (30 h with backlight) |
| Housing material | plastic |
| Weighing plate | stainless steel |
| Operating temperature | 0 °C to 40 °C |
| Net weight | 20 kg |
| Weight | 22 kg |
| Manufacturer | Kern |
| EAN | 4045761252639 |
| HS-Code | 84238220 |
| GPSR manufacturer information | KERN & SOHN GmbH, Ziegelei 1, DE-72336 Balingen-Frommern, www.kern-sohn.com |
| Condition of article | New |
| Article authenticity | Original product |
| Country of Manufacture | China |
| Material | Plastic |
| Wägebereich max (g) | 150000 |
| Ablesbarkeit (g) | 10 |
| Display type | LED segments |
