LEANLED II surface-mounted light 180 mm, 120° clear, ~4,3 W, 24V DC - LED2WORK 111010-01

The LEANLED II lights machines and plant where space is tight: at a cross-section of just 31 x 26 mm, the 180 mm bar delivers 750 lm for bright, detail-true illumination.

Key benefits

• Very slim: a 31 x 26 mm cross-section fits discreetly into the machine area.
• Clear cover, 120°: bright, detailed lighting for tasks that need high illuminance.
• High efficiency: ~173 lm/W at 750 lm luminous flux.
• M12 A-coded: fast, tool-free connection to 24V DC.
• Ready to mount: two pairs of brackets included, for flat fixing and 360° swivel alignment.
• Long service life: over 100,000 h (L80/B10) in an aluminium housing.

Technical data

• Model: LEANLED II, clear cover
• Design: surface-mounted LED light
• Light source: SMD LED
• Power: ~4,3 W
• Luminous flux: 750 lm
• Luminous efficacy: ~173 lm/W
• Light colour: 5700K 3-step MacAdam
• Colour rendering (Ra): >85
• Supply voltage: 24V DC ± 10%
• Connection: M12 A-coded
• Protection rating: IP54
• Protection class: III
• Beam angle: 120°
• Operating temperature: -10 °C - +60 °C
• Service life: > 100.000 h (L80/B10)
• Housing material: aluminium
• Cover material: polycarbonate, clear, splinter-free
• Cross-section: 31 mm x 26 mm
• Length: 180 mm
• Weight: 210 g
• Risk group (DIN EN 62471): exempt group
• Certifications: CE, UKCA, ETL Listed (5003529), D-Kennzeichnung
• Made in: Germany

Applications

• Work-area and interior lighting in machines and plant
• Assembly and inspection stations needing fine detail
• Control cabinets and confined installation spaces

Scope of supply and standards

Includes 1x LED bar, 1 pair of brackets for flat mounting, 1 pair for 360° swivel mounting. Dimming accessory optional. Made in Germany. Certifications: CE, UKCA, ETL Listed (5003529), D mark. Exempt group per DIN EN 62471.
