DIN rail power supply 72W 24V DC for LED2WORK lights - LED2WORK 210100-01

This 24V DC switching power supply powers all LED2WORK 24V DC lights and mounts directly onto a DIN rail via screw terminals. In an enclosed industrial design, it delivers up to 72 W of stable output and covers a wide input voltage range.

Your benefits

• 72 W of stable 24V DC output for LED2WORK lights
• Wide input voltage range from 88 to 264V AC
• Protection against short circuit, overload, over-voltage and over-temperature
• Easy DIN rail mounting via screw terminals
• High efficiency of 89 % at full load
• Dimmable in combination with PWM dimmers from LED2WORK

Technical data

• Model: Constant-voltage power supply
• Type: DIN rail switching power supply
• Nominal output voltage: 24V DC
• Max. output power: 72 W (76.8 W)
• Output current: 3200 mA
• Input voltage: 88 to 264V AC
• Input frequency: 47 to 63 Hz
• Efficiency at full load: 89 %
• Ambient temperature: -30 °C to +70 °C
• Over-temperature protection: 100 °C ± 10 °C
• Dimensions: 32 mm x 125.2 mm x 102 mm
• Weight: 450 g
• Protective devices: short-circuit, overload, over-voltage, over-temperature protection
• Certifications: CE, CB, UKCA, UL508 approved, ITE EN/UL/IEC 60950

Applications

For powering LED2WORK 24V DC lights in the control cabinet and in the machine. When selecting, check the power consumption and connection ratings of your luminaire.
