LEANLED II Basic-Line LED Machine Light 1020 mm, clear Cover, 23,1 W, IP54 - LED2WORK 111010-46

The LEANLED II Basic-Line lights machines, plant and workstations over 1020 mm of length with 3570 lm, delivering homogeneous, flicker-free light from a design just 31 mm flat.

Key benefits

• Cost-optimised Basic-Line for price-sensitive applications at full LED2WORK quality
• 3570 lm at 5700K 3-step MacAdam with >80 colour rendering for clear sight at the workplace
• Very flat design at just 31 mm high, fits even where space is tight
• High luminous efficacy of 155 lm/W at only 23,1 W input power
• IP54 and an aluminium housing for use in machine and industrial environments

Technical data

• Model: LEANLED II Basic-Line klar
• Design: surface-mounted LED light
• Power: 23,1 W
• Luminous flux: 3570 lm
• Luminous efficacy: 155 lm/W
• Light colour: 5700K 3-step MacAdam
• Colour rendering (Ra): >80
• Beam angle: 120°
• Supply voltage: 24V DC
• Connection: M12 A-coded
• Protection rating (IP): IP54
• Protection class: III
• Operating temperature: 0 °C - +45 °C
• Service life: > 60.000 h (L70/B50)
• Housing material: aluminium
• Cover material: polycarbonate
• Dimensions (W x H x L): 26 mm x 31 mm x 1020 mm
• Weight: 780 g
• Risk group (DIN EN 62471): Exempt group
• Certifications: CE, UKCA
• Made in: Germany

Applications

Control cabinet construction, machine and plant building and general workplace lighting in industrial settings, wherever economical yet capable LED lighting is required.

Mounting and scope of delivery

Swivel and fixed brackets for mounting are included. At a supply voltage below 24V DC the luminous flux is reduced.
