SIGNALED II RGB signal light 760 mm, 120°, IP54, 24V DC - LED2WORK 111090-15

To make machine states recognisable at a glance, the SIGNALED II RGB signals through coloured light and flashing. Over a 760 mm body length, the surface-mounted light mixes red, green and blue into a colour space of at least 2563 colours and spreads it across a 120° beam angle.

Key benefits

• Signals states through coloured light and flashing, RGB colour space of at least 2563 colours
• Even light distribution across a 120° beam angle
• IP54 protection rating for use on machines without chip impact or coolant
• Aluminium housing with polycarbonate cover, opal-white glare control
• Service life of more than 100,000 h (L80/B10)
• Two pairs of brackets included for fixed or movable mounting

Technical data

• Model: SIGNALED II RGB
• Design: LED surface-mounted light
• Light source: RGB LED
• Power: approx. 4.24 W (red), approx. 2.96 W (green), approx. 4.24 W (blue)
• Luminous flux: 273 lm (red), 504 lm (green), 165 lm (blue)
• Light colour: RGB colour space (at least 2563 colours)
• Light distribution: direct
• Beam angle: 120°
• Glare control: opal white
• Supply voltage: 24V DC -10 % +7 % (RGB)
• Connection: M12 A-coded
• Protection rating (IP): IP54
• Protection class: III
• Operating temperature: -10 °C to +50 °C
• Service life: > 100,000 h (L80/B10)
• Housing material: aluminium
• Cover material: polycarbonate
• Dimensions: 760 mm x 30 mm x 25 mm (L x W x H)
• Weight: 620 g
• Risk group (DIN EN 62471): exempt group
• Dimmable: no
• Certifications: CE, UKCA, ETL Listed (5003529), D mark
• Made in: Germany

Applications

Suitable for machines and systems without chip impact or coolant, and for conveyors, roller doors and logistics workstations where states are to be indicated by coloured light.
