DOMELED multicolour signal light Ø50 mm, 180°, 24V DC, IP67 - LED2WORK 130190-01

Images are examples, some edited with AI. The technical data are authoritative. AI notice

DOMELED multicolour signal light Ø50 mm, 180°, 24V DC, IP67 - LED2WORK 130190-01

Name: DOMELED multicolour signal light Ø50 mm, 180°, 24V DC, IP67 - LED2WORK 130190-01
Brand: LED2WORK
SKU: L2W-130190-01
Price: 58.52 EUR
Availability: InStock

LED2WORK ✓ Original product Brand new Made in China

Compact multicolour signal light, 50 mm diameter with a 180° optic for visibility from any direction. A multicolour chip shows white, red, green, blue and yellow, and IP67 makes it water- and dust-tight.

Net

€58.52

excl. VAT

Item L2W-130190-01

Manufacturer no. 130190-01

Question about this item

Datasheet (PDF) User manual 5 documents, all under Downloads

Specialist dealer since 2009
Invoice payment for regular customers
Worldwide shipping
Technical questions clarified with the manufacturer

Description

For clear status and signalling on machines, the DOMELED with a 50 mm diameter offers a 180° optic visible from all directions and shows several standard colours from a single multicolour chip.

Key benefits

Multicolour chip for white, red, green, blue and yellow in one housing
180° optic with translucent cover for even light distribution
High efficacy of 160 lm/W, white at 282 lm and 1,8 W
IP67 rating, water- and dust-tight for harsh environments
Long service life of > 60,000 h (L80/B10)
Colour priority: red over yellow, green, blue and white, plus a 2 Hz flashing input

Applications

Status and signalling on machines, plant and workstations needing a compact multicolour light visible from any direction. Mounting optional.

Technical data

Model	DOMELED
Power white	1,8 W, red: 1,5 W, green: 1,3 W, yellow: 1,3 W, blue: 1,7 W
Luminous flux white	282 lm
Luminous efficacy white	160 lm/W
Light colour white	5000K (daylight white)
Colour rendering white (Ra)	>85
Supply voltage	24 V DC
Connection	M12 A-coded, 8-pole
Protection rating	IP67
Protection class	III
Beam angle	180°
Operating temperature	-20 °C to +50 °C
Service life	> 60,000 h (L80/B10)
Housing material	PC
Dimensions (H x W)	74 mm x 50 mm, length: 50 mm
Weight	70 g
Risk group (DIN EN 62471)	exempt group
Dimmable	No
Certifications	CE, UKCA, ETL Listed (5003529)
Manufacturer	LED2WORK
Manufacturer Nr.	130190-01
HS-Code	94054239
GPSR manufacturer information	LED2WORK GmbH, Stuttgarter Straße 13 A, 75179 Pforzheim www.led2work.com
Condition of article	New
Article authenticity	Original product
Country of Manufacture	China
Norm	DIN EN 62471
Control and dimming	Dimmable
Luminous flux (lumen)	160 lm
Power (W)	1.8 W
Colour temperature	5000K
Operating voltage	24 V
Protection class (IP)	IP67
