Profiled pendant LED profile light 1000 mm dimmable, 3674 lm, 5700K, 100° - LED2WORK 150714-06
LED profile light on spring-balance pendant suspension for flexible workstation lighting, 1000 mm long with 3674 lm luminous flux and an even 100° distribution. The height-adjustable pendants vary the illuminance, supplied with 120-277V AC from the ceiling feed point.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
The PROFILED on spring-balance pendant suspension lights manual and workshop stations flexibly. Over 1000 mm it delivers 3674 lm, and the height-adjustable pendants pull the light down or push it up to set the illuminance at the workstation.
Benefits
- Height adjustment via spring-balance pendants with coiled cable, travel range ~900 mm - 1800 mm
- Even area lighting from a 100° beam angle and microprism optics
- Brightness adjustable via a push button on the side of the housing
- 3674 lm at around ~27 W, roughly 155 lm/W luminous efficacy
- Long service life of over 100,000 h (L80/B10), maintenance-free
- Sturdy aluminium housing, neutral white 5700K light with Ra above 85
Applications
For manual workstations and workshops where the light should be brought close to the work surface via the pendants. Mounting accessories are available as an option.
Technical data
| Model | PROFILED Zugpendel |
|---|---|
| Design | profile light with pendant suspension |
| Light source | SMD LED |
| Total power incl. driver | ~27 W |
| Power | ~23 W |
| Luminous flux | 3674 lm |
| Luminous efficacy | ~155 lm/W |
| Light colour | 5700K 3-step MacAdam |
| Colour rendering (Ra) | >85 |
| Supply voltage | 120-277V AC ± 10%, 50-60 Hz |
| Connection | spring-balance pendant suspension |
| Dimmable | Ja, Taster seitlich |
| Protection rating (IP) | IP40 |
| Protection class | I |
| Beam angle | 100° |
| Operating temperature | -10 °C to +45 °C |
| Service life | > 100,000 h (L80/B10) |
| Housing material | aluminium |
| Cover material | plastic |
| Pendant travel range | ~900 mm - 1800 mm |
| Dimensions | 1000 mm x 65 mm x 45 mm |
| Weight | 3040 g |
| Risk group (DIN EN 62471) | exempt group |
| Certifications | CE, UKCA |
| Made in | Germany |
| Manufacturer | LED2WORK |
| Manufacturer Nr. | 150714-06 |
| HS-Code | 94054239 |
| GPSR manufacturer information | LED2WORK GmbH, Stuttgarter Straße 13 A, 75179 Pforzheim www.led2work.com |
| Condition of article | New |
| Article authenticity | Original product |
| Country of Manufacture | Germany |
| Norm | DIN EN 62471 |
| Control and dimming | Dimmable |
| Luminous flux (lumen) | 3674 lm |
| Power (W) | 27 W |
| Colour temperature | 5700K |
| Mounting type | Pendant, T-slot / profile |
| Operating voltage | 120-277 V |
| Protection class (IP) | IP40 |
