FIELDLED EVO recessed 280x96 mm machine light 19W, 100°, M12 rear, IP67/IP69K - LED2WORK 153010-12

LED2WORK ✓ Original product Brand new Made in Germany

High-output LED machine light as a recessed light with 3000 lm from 19 W for even, glare-free lighting of large machines. Safety glass, a metal housing and IP67/IP69K protect against chips and coolant.

Net
€209.35
excl. VAT
Item L2W-153010-12
Manufacturer no. 153010-12
Question about this item
  • Specialist dealer since 2009
  • Invoice payment for regular customers
  • Worldwide shipping
  • Technical questions clarified with the manufacturer

Description

For even, flicker- and glare-free lighting of large plant, the FIELDLED EVO recessed delivers 3000 lm from around 19 W with microprism glare control, ideally for harsh settings such as metal machining.

Key benefits

  • High output of 3000 lm at around 19 W, 155 lm/W
  • Microprism glare control for flicker- and glare-free light
  • IP67/IP69K rating against chips, dust and coolant
  • Aluminium metal housing with shatterproof toughened safety glass (ESG)
  • Vibration-resistant at 10 to 55 Hz and shock-resistant up to 50 g
  • M12 connection on the rear, reverse-polarity-safe at 24V DC

Applications

Lighting of machine tools and large plant, ideally in metal machining. The recessed light retrofits into almost any machine tool.

Technical data

ModelFIELDLED EVO recessed, M12 rear
Designrecessed LED machine light
Light sourceSMD LED
Power~19 W
Luminous flux3000 lm
Luminous efficacy155 lm/W
Light colour5700K 3-step MacAdam
Colour rendering (Ra)>85
Supply voltage24V DC ± 10%
ConnectionM12 A-coded, rear
Protection ratingIP67/IP69K
Protection classIII
Glare controlmicroprisms
Beam angle100°
Operating temperature-30 °C to +60 °C
Service life> 100,000 h (L80/B10)
Vibration resistance10 to 55 Hz (amplitude 0.35 mm)
Shock resistanceup to 50 g
Housing materialaluminium
Cover materialESG (safety glass), shatterproof
Dimensions (H x W)30 mm x 96 mm, Rahmen: 5,6 mm x 132 mm, length: 280 mm
Weight1180 g
Risk group (DIN EN 62471)exempt group
Dimmableoptional via accessory
Mountingintegrated frame with Ø 6.5 mm holes
CertificationsCE, UKCA, ETL Listed (5003529)
Made inGermany
ManufacturerLED2WORK
Manufacturer Nr.153010-12
HS-Code94054239
GPSR manufacturer informationLED2WORK GmbH, Stuttgarter Straße 13 A, 75179 Pforzheim www.led2work.com
Condition of articleNew
Article authenticityOriginal product
Country of ManufactureGermany
NormDIN EN 62471
Control and dimmingDimmable
Luminous flux (lumen)3000 lm
Power (W)19 W
Colour temperature5700K
Mounting typeRecessed
Operating voltage24 V
Protection class (IP)IP69K
