DIMMbox external with 3 m cable, M12 A-coded for T-slot, max. 96 W - LED2WORK 210700-06

For stepless dimming of LED2WORK 24V DC lights, this DIMMbox sets brightness with a rotary potentiometer and its fixed 3 m cable puts distance between the control and the light, for a connected load up to 96 W.

Key benefits

• Stepless brightness control via rotary potentiometer
• Built-in on/off switch on the module
• 3 m cable on the M12 output for flexible placement
• M12 input (socket) and M12 output (plug), both A-coded
• Mounts directly onto T-slot profiles via fixing tabs
• Connected load up to 96 W, current rating up to 4000 mA

Technical data

• Model: LED2WORK DIMMbox
• Design: surface module with slot mounting
• Power: max. 96 W
• Input/output voltage: 24V DC
• Max. current rating: 4000 mA
• Brightness control: rotary potentiometer
• Input/output connection: plug M12A / socket M12A with 3 m cable
• On/off switch: yes
• Driver: external
• Protection rating: IP54
• Protection class: III
• Operating temperature: -20 °C to +50 °C
• Storage temperature: -20 °C to +80 °C
• Material: ABS housing
• PWM frequency: ~4.9 kHz
• Dimensions: 122 mm x 38 mm x 45 mm
• Weight: 450 g
• Certifications: CE, UKCA

Applications

Universal DIMMbox for all LED2WORK 24V DC lights with an A-coded M12 connection, except RGB models. The 3 m cable allows control away from the luminaire location.
