TSOP-40 Pik-Tip 9.9 x 19.3 mm for Sodr-X-Tractor SX - PACE 1121-0568

Name: TSOP-40 Pik-Tip 9.9 x 19.3 mm for Sodr-X-Tractor SX - PACE 1121-0568
Brand: PACE
SKU: PC-1121-0568
Price: 67.90 EUR
Availability: InStock

PACE ✓ Original product Brand new Made in United States

TSOP-40 Pik-Tip, 9.9 x 19.3 mm, for the PACE Sodr-X-Tractor SX-70, SX-80, SX-90 and SX-100. Made for the wider TSOP-40 body that is common on flash memory.

Net

€67.90

excl. VAT

Item PC-1121-0568

Manufacturer no. 1121-0568

Question about this item

Datasheet (PDF) 3 documents, all under Downloads

Specialist dealer since 2009
Invoice payment for regular customers
Worldwide shipping
Technical questions clarified with the manufacturer

Description

TSOP-40 devices often serve as flash memory and have to come off intact for replacement or readout. This Pik-Tip, 9.9 x 19.3 mm (0.390 x 0.760 in), heats both 20-lead rows at once, and the integral pick lifts the package using the station vacuum.

Benefits

9.9 x 19.3 mm for the TSOP-40 outline
Both lead rows reach solder melt temperature together
Device stays on the pick, no extra tweezer handling

Specifications

Applications

Removing TSOP-40 flash memory for replacement or readout
Rework on control and communication boards

Compatibility

SX-100 Sodr-X-Tractor IntelliHeat (6010-0149)
SX-90, SX-80 and SX-70 Sodr-X-Tractor

Technical data

Part number	1121-0568
Type	Pik-Tip, SMD removal tip with vacuum pick
Package	TSOP-40
Size A x B	9.9 x 19.3 mm
Handpiece	PACE SX-100, SX-90, SX-80, SX-70
Sales unit	1 piece
Weight	0.01 kg
Manufacturer	PACE
Manufacturer Nr.	1121-0568
HS-Code	85159080
GPSR manufacturer information	A1-ESD equipment GmbH. Keldersstr. 15, DE-42697 Solingen, www.esd.equipment
Condition of article	New
Article authenticity	Original product
Country of Manufacture	United States
Tip diameter/width [mm]	9.9
Soldering tip shape	sonstige
Series	SX-90/SX-100
