Pik-Tip Removal Tip TQFP-28, 8.2 x 8.23 mm, for Sodr-X-Tractor SX-70 to SX-100 - PACE 1121-0571

Small TQFP-28 packages often sit tightly between decoupling capacitors, and prying with tweezers or wire puts the pads at risk. This Pik-Tip places an 8.2 x 8.23 mm frame on all four lead rows, melts the solder all around at the same time and lifts the part off in a single move using vacuum.

Benefits

• 8.2 x 8.23 mm frame matched to the compact TQFP-28 body, neighbouring parts stay clear
• Integral vacuum pick, the part is removed one-handed without tweezers
• Fits any Sodr-X-Tractor SX-100, SX-90, SX-80 and SX-70, vacuum is supplied by the power source

Specifications

Applications

• Replacing faulty microcontrollers and drivers in TQFP-28 packages
• Repair of densely populated control boards
• Removing parts for failure analysis
