ST 325 Digital Programmable Hot Air Reflow System, 230 V, 750 W - PACE 8007-0432

Replacing the same SMD components again and again calls for repeatable cycles. The ST 325 stores up to 20 time and temperature profiles (40 with optional software) and controls the hot air flow between 176 and 482 °C at 5 to 22 SLPM.

Benefits

• 750 W handpiece with integrated spring-loaded vacuum pick, position adjustable over 38 mm (1.5 in).
• Tool-free nozzle adaptor, 4028 nozzles change in seconds.
• Quiet-Flo turbine blower, airflow stops immediately with no heater cool-down period.
• Hi-Flo vacuum pump holds the component, Lo-Flo pump serves the included PV-65 Pik-Vac wand.
• Multi-level password lock-out and audible countdown at the end of the cycle.

Specifications

Applications

• Installing and removing SMD components in single and batch rework
• Process-controlled rework with stored profiles

Compatibility

• 4028-xxxx hot air nozzles for ST 300/325/350, replacement heater 6010-0122-P1 (230 V)
• ST500A Z-axis platform, ST525 and ST550 PCB holders
• PH 100, ST 400 or ST 1600 preheaters
