3/8" Allen Socket Bit HX 4 mm, 50 mm - Proxxon 23575
Allen socket bit with 3/8" square drive and 4 mm hex blade, 50 mm long, for driving hexagon socket screws with a ratchet. The chrome-silicon-manganese-molybdenum blade sits in a CrV steel base for high torque transfer.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
The 3/8" Allen socket bit HX 4 mm joins a 4 mm hexagon blade firmly to a 3/8" square base. This lets you tighten and loosen hexagon socket screws directly with a 3/8" ratchet instead of an L-key.
- Chrome-silicon-manganese-molybdenum blade: high strength for transmitting torque through the hex.
- CrV steel base: sturdy 3/8" square drive, fits Proxxon 3/8" ratchets and extensions.
- 50 mm length: reaches recessed screws as well.
Technical data
| Drive | 3/8" square |
|---|---|
| Profile | hexagon socket HX |
| Width across flats | 4 mm |
| Length | 50 mm |
| Blade | chrome-silicon-manganese-molybdenum steel |
| Base | CrV steel |
| Weight | 0.042 kg |
| Manufacturer | Proxxon |
| Manufacturer Nr. | 23575 |
| EAN | 4006274235755 |
| HS-Code | 82042000 |
| GPSR manufacturer information | PROXXON S.A. Härebierg 6-10, LU-6868 Wecker, www.proxxon.com |
| Condition of article | New |
| Article authenticity | Original product |
| Country of Manufacture | Taiwan |
| ESD version | TEC |
Suited to repair, assembly and machine building wherever hexagon socket screws are driven with a ratchet.
