Ersatz-Thermoelement für Lötbad 100-15S - Quick QUTE100-15S

In dip soldering the result stands or falls with the bath temperature. The 100-15S controls between 100 and 450 °C at 600 W, and the actual value behind that control loop comes from this thermocouple. Jumping readings, a frozen value or an error message put the sensor first on the list.

Features

• Genuine spare for the Quick 100-15S, so probe length and connection need no adaptation.
• Covers the full control range of the bath from 100 to 450 °C.
• A drifting sensor falsifies the temperature without the unit failing outright, which is why it is checked first when readings look implausible.
• The rectangular crucible measures 98 x 121 mm at 58 mm depth and is surrounded by the heating element at the sides, so the probe position matters.
• Prerequisite for the digital calibration of the bath, which is meaningless without a reliable actual value.

Technical data

Application

Dip soldering and tinning in production, cable assembly and rework, wherever the bath temperature has to be documented and repeated.

Scope of delivery

One QUTE100-15S thermocouple.

Compatibility

Quick 100-15S solder bath. The 854 heating plate uses the external type K thermocouple QUTE854 instead, the two are not interchangeable. The 100-15S exists with metal and with ceramic heating elements, so the variant matters for parts of the heating circuit.
