Sicherheits-Gehäuse mit Vorhang-Lichtschranke und Prozessbeleuchtung - Quick QUSAFETYL
Transparent safety enclosure with light curtain and process lighting that turns a Quick soldering robot into a closed work cell. The curtain stops the machine on intrusion while the clear build and the lighting keep the running process in view. ESD safe design for work on electronic assemblies.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
A soldering robot works with a hot tip and moving axes. Running it in an open setup means relying on operator attention. This enclosure replaces that assumption with a technical safeguard, since the light curtain registers any reach into the cell.
Features
- Light curtain as a monitored access point, registering entry into the working area.
- Transparent construction, so the process can be watched without opening the cell.
- Integrated process lighting, which keeps the joint visible inside the closed enclosure.
- ESD safe design, in line with handling electronic assemblies around the cell.
- Offered as an option for Quick soldering robots, in particular the four axis Basic and two table systems.
Applications
Automated soldering cells in electronics production where operators load and unload work regularly, and any setup where a risk assessment calls for a guard with monitored access.
Technical data
| Brand | Quick |
|---|---|
| Part number | QUSAFETYL |
| Type | safety enclosure |
| Protective device | light curtain |
| Lighting | integrated process lighting |
| Design | transparent |
| ESD | ESD safe |
| Use | option for Quick soldering robots, four axis Basic and two table systems |
| Manufacturer | Quick |
| Manufacturer Nr. | QUSAFETYL |
| GPSR manufacturer information | Bräunlich GmbH Am Heideberg 26, DE 06886 Lutherstadt Wittenberg, www.braeunlich-gmbh.com |
| Condition of article | New |
| Article authenticity | Original product |
Scope of delivery
One safety enclosure with light curtain and process lighting. The soldering robot itself, the soldering tool and the feed system are not included. Integration into the safety chain of the machine and acceptance of the cell remain the responsibility of the operator.
