Load Cell 250 kg - SAUTER CB 250-3P1

For weight and compression-force measurement in demanding conditions, the SAUTER CB 250-3P1 carries up to 250 kg rated load: a bending beam load cell in nickel-plated steel, legal-for-trade as an OIML R60 class C3 component.

Benefits

• Legal-for-trade component: OIML R60 class C3, 3000 divisions (e), Y value 10000
• Durable housing: nickel-plated steel for demanding environments
• Wide temperature range: use from -35 to 65 deg C
• Ready to fit: 4 m cable, 4-wire connection, compression loading

Technical data

• Rated load (Max): 250 kg
• Accuracy class: OIML R60 class C3, 3000 e, Y value 10000
• Design: bending beam load cell
• Material: nickel-plated steel
• Force direction: compression
• Ambient temperature: -35 to 65 deg C
• Cable length: 4 m
• Connection: 4-wire
• Net weight: 0,90 kg

Applications

Suited to platform, hopper and floor scales and other weighing devices in industry and manufacturing, the chemical industry, food and pharma, building materials, and logistics and packaging.

Compliance and origin

OIML R60 class C3. EAN 4045761228085, customs tariff number 84239010, country of origin China.
